Mean Well GC120A24-AD1 Portable Chargers 120.2W 27.2V 4.42A - Green...
The GC120A24 is a 120W Mean Well power converter.
Key Features
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Safety approvals: EN62368-1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGC Series
-
Power Rating120.2 Watt
-
Output Voltage27.2 Volt
-
Rated Current4.42 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.57 in
-
Width2.64 in
-
Height1.38 in
-
Weight1.37 lb
::specification::
Frequently Asked Questions
What is the output rating of the Mean Well GC120A24-AD1?
The GC120A24-AD1 is rated for 120.2W with a 27.2V DC output and 4.42A rated current. That makes it a portable charger for 24V-class charging applications that need a regulated 27.2V output.
What input power range does the GC120A24-AD1 support?
This model accepts a universal 85 to 264VAC input range and also supports 120 to 370VDC input. It uses a 3-pole IEC320-C14 AC inlet and includes active PFC for broad mains compatibility.
What kinds of applications is the GC120A24-AD1 best suited for?
The GC120A24-AD1 is intended for portable 24V charging duties where a 27.2V, 4.42A output is appropriate. Buyers typically look at this type of unit for service, field, or bench charging needs where a compact enclosed charger is preferred.
What protection features are built into the GC120A24-AD1?
This charger includes short circuit, overload, over voltage, and over temperature protection. Overload protection operates at 90 to 110% constant current with auto-recovery, while over voltage protection shuts down the output and requires re-powering to recover.
Can the GC120A24-AD1 be used in demanding temperature conditions?
The specified working temperature range is -30 to +70 degrees C, subject to the derating curve. Cooling is by free air convection, so it is designed to operate without an internal fan.
What connector and cable does the GC120A24-AD1 use on the DC output side?
The standard DC plug is a Power DIN 4P lock-type connector identified as R7B. The output cable length is 120cm and uses UL2464 18AWG 4-conductor cable.
How does the GC120A24-AD1 compare with lower-power 24V chargers?
The main difference is output capacity: the GC120A24-AD1 delivers up to 120.2W and 4.42A at 27.2V. For buyers comparing portable 24V chargers, this model is positioned for applications that need more charging current than smaller wattage units can provide.
What status and efficiency features does the GC120A24-AD1 offer?
This model provides a 2-color LED indicator for charging status and uses a 2-stage charging characteristic. It also reaches up to 91% efficiency and keeps no-load power consumption below 0.5W.
