Mean Well MPS-30-27 Power Supply 30W 27V
Description
Description
MEAN WELL MPS-30 Series Power Supplies are 30W singlel output medical type power supplies low cost ,high reliability with 3 years warranty.
Features
- Universal AC input / Full range
- Low leakage current <200pA
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Medical safety approved (2 x MOPP between primary to secondary)
- Fixed switching frequency at 100KHz
- Low cost
- High reliability
- 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating29.7 Watt
-
Output Voltage27 Volt
-
Rated Current1.1 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty3 Year
-
Length4 in
-
Width2.59 in
-
Height0.93 in
-
Weight0.35 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the MPS-30-27 for a 27V industrial control or instrumentation load?
Yes, if the equipment requires constant-voltage 27V DC and draws no more than 1.1A. Its maximum output is 29.7W, so it fits lighter-duty 27V control and instrumentation applications.
Is this power supply suitable for a 27V embedded device or bench test assembly?
It can support a 27V embedded or test load when the total demand remains within 1.1A and 29.7W. The wide 88-264VAC input range also makes it practical for use across different AC supply regions.
Can the MPS-30-27 run a small 27V automation module continuously?
It is intended for constant-voltage 27V output and can power small automation modules that stay inside the 29.7W rating. Loads that need more than 1.1A would require a higher-capacity 27V sibling.
Is the MPS-30-27 meant for outdoor cabinets or exposed environments?
The product is specified for operation from -10°C to +60°C. No IP rating is listed, so the published specs do not indicate suitability for exposed outdoor use.
How does the MPS-30-27 differ from the other compact MPS output versions?
The related lower-power models are MPS-30-5 at 25W, 5V, 5A; MPS-30-12 at 30W, 12V, 2.5A; MPS-30-15 at 30W, 15V, 2A; MPS-30-24 at 28.8W, 24V, 1.2A; and MPS-30-48 at 28.8W, 48V, 0.6A. The MPS-30-27 version is rated at 29.7W, 27V, 1.1A.
Other MPS-30 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well MPS-30-5 Power Supply 30W 5V | 25W | 5V | 5A | Indoor | $38.92 | View |
| Mean Well MPS-30-48 Power Supply 30W 48V | 28.8W | 48V | 0.6A | Indoor | $38.92 | View |
| Mean Well MPS-30-24 Power Supply 30W 24V | 28.8W | 24V | 1.2A | Indoor | $38.92 | View |
| Mean Well MPS-30-15 Power Supply 30W 15V | 30W | 15V | 2A | Indoor | $38.92 | View |
| Mean Well MPS-30-12 Power Supply 30W 12V | 30W | 12V | 2.5A | Indoor | $38.92 | View |
