Mean Well MPS-30-48 Power Supply 30W 48V 600mA
MEAN WELL MPS-30 Series Power Supplies are 30W singlel output medical type power supplies low cost ,high reliability with 3 years warranty.
Key Features
- ✓Universal AC input / Full range
- ✓Low leakage current <200pA
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Medical safety approved (2 x MOPP between primary to secondary)
- ✓Fixed switching frequency at 100KHz
- ✓Low cost
- ✓High reliability
- ✓3 years warranty
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating28.8 Watt
-
Output Voltage48 Volt
-
Rated Current0.6 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty3 Year
-
Length4 in
-
Width2.59 in
-
Height0.93 in
-
Weight0.35 lb
::specification::
Frequently Asked Questions
Can I use the MPS-30-48 for a 48V industrial communication or control device?
Yes, if the equipment requires constant-voltage 48V DC and draws no more than 0.6A. The total output capacity is 28.8W, so it is intended for lighter 48V electronics rather than higher-current 48V loads.
Is this suitable for a compact 48V embedded or automation module?
It can be used where a compact module needs 48V DC and stays within 0.6A output current. For 48V devices with higher steady-state demand, this model would not provide enough current headroom.
Can the MPS-30-48 power a small 48V control interface in an industrial enclosure?
It is a constant-voltage 48V supply rated for 28.8W, so it fits small 48V control interfaces that remain within that power envelope. Its 88-264VAC input range also supports use with a broad range of AC input sources.
Is the MPS-30-48 appropriate for damp or outdoor locations?
The published temperature range is -10°C to +60°C. Since no IP rating is included in the specs, the product data does not support classifying it as an outdoor-rated or water-resistant power supply.
What are the output differences between the MPS-30-48 and the other small MPS versions?
In the smaller MPS range, MPS-30-5 is 25W, 5V, 5A; MPS-30-12 is 30W, 12V, 2.5A; MPS-30-15 is 30W, 15V, 2A; MPS-30-24 is 28.8W, 24V, 1.2A; and MPS-30-27 is 29.7W, 27V, 1.1A. The MPS-30-48 version is rated at 28.8W, 48V, 0.6A.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other MPS-30 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well MPS-30-5 Power Supply 30W 5V 5A | 25W | 5V | 5A | Indoor | $38.92 | View |
| Mean Well MPS-30-27 Power Supply 30W 27V 1.1A | 29.7W | 27V | 1.1A | Indoor | $38.57 | View |
| Mean Well MPS-30-24 Power Supply 30W 24V 1.2A | 28.8W | 24V | 1.2A | Indoor | $38.92 | View |
| Mean Well MPS-30-15 Power Supply 30W 15V 2A | 30W | 15V | 2A | Indoor | $38.92 | View |
| Mean Well MPS-30-12 Power Supply 30W 12V 2.5A | 30W | 12V | 2.5A | Indoor | $38.92 | View |
