Mean Well NPB-360-24AD1 Battery Charger 360W 24V Anderson Connector
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NPB-360-24AD1 Battery Charger 360W 24V Anderson Connector
Description
Description
Specifications
Specifications
-
BrandMean Well
-
SeriesNPB Series
-
Power Rating360 Watt
-
Output Voltage28.8 Volt
-
Rated Current12 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length7.09 in
-
Width3.78 in
-
Height1.93 in
-
Weight2.87 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What are the main output specs of the Mean Well NPB-360-24AD1 battery charger?
The NPB-360-24AD1 is a 360W AC-DC battery charger with a 28.8V DC output and 12A rated current. It is built as a single-output charger and includes power factor correction. This model is intended for 24V battery charging applications that match its output rating.
Is the NPB-360-24AD1 suitable for portable or field-use charging setups?
This model is commonly suited to portable charging use where a 24V battery charger with a compact industrial form factor is needed. Its 1.3 kg weight makes it more manageable than heavier bench-style charging equipment. Buyers looking for a transportable 24V charger often consider this type of unit for service, maintenance, or mobile equipment support.
What charging method does the NPB-360-24AD1 use?
The NPB-360-24AD1 supports 2-stage or 3-stage charging, depending on the application requirements. That makes it more application-specific than a simple fixed-output power supply. For buyers comparing charger types, this is an actual battery charger rather than just a generic 24V DC source.
What connector type is used on the NPB-360-24AD1?
This specific model version uses an Anderson connector on the output side. That is a useful distinction when comparing it with other chargers in the same power class, because connector style can affect product compatibility with existing equipment. If your standard is an Anderson-style interface, this model is designed around that format.
Can the NPB-360-24AD1 operate in demanding temperature conditions?
The rated operating temperature range is -30°C to 70°C, which is broad for an industrial battery charger. That makes it relevant for buyers evaluating chargers for cold environments, warmer plant conditions, or mixed indoor and light industrial settings. Environmental suitability should still be reviewed against the full system conditions and enclosure design.
What warranty is offered for the Mean Well NPB-360-24AD1?
The listed warranty period for the NPB-360-24AD1 is 3 years. That gives B2B buyers a clear support window when evaluating lifecycle cost and supplier fit. It also helps distinguish this charger from lower-tier alternatives with shorter warranty coverage.
