Mean Well NPB-360-48TB Battery Charger 360W 48V Terminal Block
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NPB-360-48TB Battery Charger 360W 48V Terminal Block
Description
Description
Specifications
Specifications
-
BrandMean Well
-
SeriesNPB Series
-
Power Rating360 Watt
-
Output Voltage57.6 Volt
-
Rated Current6 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length7.09 in
-
Width3.78 in
-
Height1.93 in
-
Weight2.87 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the output of the Mean Well NPB-360-48TB battery charger?
The NPB-360-48TB is a 360W AC-DC battery charger with a 57.6V DC output rated at 6A. This makes it a 48V-class charger intended for applications that need that charging voltage and current range.
What type of charging profile does the NPB-360-48TB support?
This model supports 2-stage or 3-stage charging. That gives buyers flexibility when selecting a charger for battery charging applications that require a controlled charging process.
Is the Mean Well NPB-360-48TB suitable for industrial or commercial battery charging use?
Yes, this model is positioned for battery charging applications where a 360W, 57.6V DC output is appropriate. Its feature set, including PFC and staged charging support, makes it relevant for professional and commercial use cases.
Does the NPB-360-48TB support a wide AC input range?
Yes, the product is specified with universal AC input. That makes it easier to use across different AC power environments without needing a model change for common input standards.
Can the NPB-360-48TB operate in demanding temperature conditions?
This charger is rated for operation from -30°C to 70°C. That wide temperature range helps it fit applications where ambient conditions may be much colder or hotter than typical indoor environments.
What are the physical and ownership considerations for the NPB-360-48TB?
The unit weighs 1.3 kg, which can matter when planning equipment layouts or transportable systems. Mean Well lists this model with a 3-year warranty period, which is useful for evaluating long-term support expectations.
