Description
Description
Features
2"x2" compact size |
2:1 wide input range |
High efficiency up to 93% |
1500VDC I/O isolation |
Built-in remote ON/OFF control |
Built-in remote sense |
Trimming output ±10% |
Comply with CE / FCC without external components |
Protection: Short circuit / Overload / Input and Output Over voltage |
Cooling by free air convection |
Six-sided shield metal case |
100% full burn-in test |
Low cost, high reliability |
Output 3.3V available |
2 years warranty |
General Specification
Voltage set point accuracy | ±2.0% (max.) |
Line regulation | ±0.5% (max.) |
Load regulation | ±0.5% |
Overload protection | 110%~250%, auto-recovery |
Efficiency | 91% ; 90.5% ; 92% | 92% ; 92.5% ; 92% | 92% ; 93% ; 92.5% |
Short circuit protection | Protection type: Hiccup mode, recovers automatically after the fault condition is removed |
I/O isolation resistance | I/P-O/P: 100M Ohms / 500VDC / 25 / 70% RH |
Working temperature | -40~+70°C (refer to output derating curve) |
Storage temperature | -55 ~ +105°C, 10 ~ 95% RH |
EMC | Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B |
Temp. Coefficient | ±0.03% /°C (0 ~ 50°C) |
Dimension (LxWxH) (mm) | 50.8 x 50.8 x 11.0 mm or 2" x 2" x 0.43" inch |
Case material | Six-sided shield metal case |
Specifications
Specifications
-
BrandMean Well
-
SeriesSKA Series
-
Power Rating60 Watt
-
Output Voltage5 Volt
-
Rated Current12 Ampere
-
Input Voltage36V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~70°C
-
Warranty2 Year
-
Length2 in
-
Width2 in
-
Height0.43 in
-
Weight0.15 lb
