Mean Well XLG-200-12-AB Power Supply 192W 12V - Adjustable and Dimmable

metal case, economical, 100~305VAC wide range input, efficiency up to 90%

SKU:

XLG-200-12-AB

Model

75W 12V Adjustable

$27.63 USD

SKU: XLG-75-12-A

75W 12V Adjustable and Dimmable

$32.50 USD

SKU: XLG-75-12-AB

100W 12V

$30.99 USD

SKU: XLG-100-12-A

100W 12V Adjustable and Dimmable

$35.71 USD

SKU: XLG-100-12-AB

150W 12V Adjustable

$34.24 USD

SKU: XLG-150-12-A

150W 12V Adjustable and Dimmable

$38.22 USD

SKU: XLG-150-12-AB

192W 12V Adjustable

$40.79 USD

SKU: XLG-200-12-A

192W 12V Adjustable and Dimmable

$45.69 USD

SKU: XLG-200-12-AB

Product variants

$45.69 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

Wide input range 100~305VAC (Class I)

Full power output at 70~100% constant power mode operation

Metal case with IP67, suitable for outdoor application

Surge protection with 6KV/4KV (10KV/6KV optional)

3 in 1 dimming function (Dim to off and isolation design)

India (EESL) version with Input Over Voltage Protection can survive input voltage stress of 440Vac for 48 hours

Protection functions: OVP/SCP/OCP/OTP

Lifetime > 50,000 hrs. and 5 years warranty

General Specification

AC input voltage range	100~305VAC;142~431VDC
AC inrush current	Cold start, 65A at 230VAC
DC adjustment range	±10% rated output voltage
Over-voltage protection	125%~150% rated output voltage
Setup, rise, hold up time	500ms, 100ms, 12ms
Withstand voltage	I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC
Working temperature	-40~+90°C
Safety standards	UL8750 approved; ENEC BS EN/EN61347-1; EAC TP TC 004; NOM-058-SCFI-2017; IP67 approved
EMC standards	EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11
Dimension (LxWxH)	199x63x35.5
Packing	16pcs / 14.2kg

Specifications

Brand

Mean Well
Series

XLG Series
Power Rating

192 Watt
Output Voltage

12 Volt
Rated Current

16 Ampere
Input Voltage

100V~305V
No of Output

1
Dimming Control

0-10V,10V PWM,Built-in Potentiometer,Resistance
Standards Met

CB,CCC,CE,EAC,ENEC,RCM,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

5 Year
Length

7.83 in
Width

2.48 in
Height

1.4 in
Weight

1.87 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can the XLG-200-12-AB power 12V LED strip in an outdoor illuminated signage cabinet?

Yes. With an IP67 waterproof rating, the XLG-200-12-AB is sealed against dust and temporary water immersion, making it suitable for outdoor sign boxes, raceways, and illuminated cabinet signage exposed to rain and humidity.

How many meters of 12V LED strip can the XLG-200-12-AB drive?

The XLG-200-12-AB delivers 192W at 12V. For a 14.4 W/m strip that is about 13.3 meters (192 ÷ 14.4); for a 9.6 W/m strip, up to 20 meters. Always confirm your strip's rated power per meter and allow a 20% safety margin when sizing the installation.

Is the XLG-200-12-AB suitable for dimmable 12V LED retail display lighting?

Yes. The AB suffix indicates this model supports dimming, making it compatible with dimming controllers used in retail display lighting that requires adjustable light levels. The 192W capacity at 12V supports wide-area display or showcase illumination.

Can I use the XLG-200-12-AB for 12V LED strip lighting in a cold room or freezer application?

Yes. The -40°C to +90°C operating temperature range allows reliable operation in sub-zero cold-room and freezer environments. The IP67 metal enclosure also withstands condensation that builds up as temperature differentials cause moisture in the air to collect on surfaces.

Is the XLG-200-12-AB a good fit for 12V LED backlighting in large menu boards or lightboxes?

Yes. At 192W and 12V, this driver can power substantial 12V LED strip areas used in backlit menu boards, trade show displays, and large lightbox graphics. The dimming feature also allows brightness adjustment to match ambient lighting conditions.

Does the XLG-200-12-AB accept both 120V and 277V input without manual adjustment?

Yes. The 100–305VAC wide-range input automatically handles both 120V and 277V commercial supplies, as well as 230V international grids. No jumper or voltage selector is required.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well XLG-200-12-A Power Supply 192W 12V - Adjustable	192W	12V	16A	IP67	$40.79	View
Mean Well XLG-200-24-A Power Supply 200W 24V - Adjustable	199.2W	24V	8.3A	IP67	$40.79	View
Mean Well XLG-200-24-AB Power Supply 200W 24V - Adjustable and Dimmable	199.2W	24V	8.3A	IP67	$45.69	View
Mean Well XLG-200-L-DA2 Power Supply 200W 700mA - DALI2 Dimmable	200W	320V	0.7A	IP67	$89.02	View
Mean Well XLG-200-H-DA2 Power Supply 200W 3500mA - DALI2 Dimmable	200W	65V	3.5A	IP67	$89.02	View
