Mean Well XLG-240-48-ABV Power Supply 240W 48V 5A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well XLG-240-48-ABV Power Supply 240W 48V 5A
Description
Description
Features:
- Wide input range 100~305V AC(Class I)
- Full power output at 70~100% Constant power mode operation
- Metal case with IP67, suitable for outdoor application
- Surge protection with 6KV/4KV (10KV/6KV optional)
- 3-in-1 Dimming function (Dim to off and Isolation design)
- Protection functions: OVP / SCP / OCP / OTP
- Lifetime >50,000 hrs
- 5 years warranty
General Specification
AC input voltage range
100 ~ 305VAC 142VDC ~ 431VDC
AC inrush current (max.)
COLD START 85A(twidth=500μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
Over-voltage protection
350 ~ 450V | 190 ~ 40V | 63 ~ 85V
(Shut down output voltage, re-power on to recovery)
Withstand voltage
I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
Working temperature
Tcase = -40 ~ +90℃ (Please refer to "OUTPUT LOAD vs TEMPERATURE" section)
Safety standards
UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384; GB19510.1, GB19510.14; EAC TP TC 004; J61347-1(H29), J61347-2-13(H29),KC61347-1,KC61347-2-13,IS15885(Part2/Sec13); NOM-058-SCFI-2017(except for Blank type); IP67 approved
Dimension (LxWxH)
219x63x35.5mm
Specifications
Specifications
-
BrandMean Well
-
SeriesXLG Series
-
Power Rating240 Watt
-
Output Voltage48 Volt
-
Rated Current5 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,RCM,SELV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~90°C
-
Warranty5 Year
-
Length8.62 in
-
Width2.48 in
-
Height1.4 in
-
Weight2.2 lb
File Downloads
File Downloads
Specification Sheet
