Mean Well QP-320F Power Supply 320W 5V 15V 24V -15V 20A
The QP is a 100W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL60950-1, TUV EN60950-1 EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesQP Series
-
Power Rating316 Watt
-
Output Voltage5 Volt
-
Rated Current20 Ampere
-
Input Voltage90V~264V
-
No of Output4
-
Standards MetCE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~70°C
-
Warranty3 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.97 in
-
Weight2.65 lb
::specification::
Frequently Asked Questions
Can I use the QP-320F for a mixed-voltage industrial control cabinet?
It can fit control systems that need multiple DC rails from one supply because this model is a quad output design with 5V, 15V, 24V, and -15V outputs. The total rated power is 316W, and the main 5V output is rated at 20A. That makes it more suitable for mixed-voltage industrial or embedded electronics than a single-output supply.
Is the QP-320F suitable for embedded test benches that need both positive and negative rails?
Yes, it is appropriate for embedded or electronics test environments that need both positive and negative DC rails, because the listed outputs include 15V and -15V along with 5V and 24V. With 316W total capacity, it is intended for systems where several regulated voltages are required from one chassis supply.
Can this power supply be used in automation equipment with a heavy 5V load?
It can suit automation or computing loads that draw heavily from 5V because the 5V output is rated at 20A. The unit is also a constant voltage design, which matches equipment that expects a fixed DC rail rather than current-regulated output.
Would the QP-320F work for industrial electronics that need wide AC input compatibility?
It is a fit for equipment that may be deployed across different AC mains regions because the input range is 90-264VAC. That makes it practical for industrial and IT hardware built for international power environments while still providing up to 316W total output.
How does the QP-320F compare with other QP series models?
Within the listed QP series, lower-power options include QP-100 variants at 100W, QP-150 variants around 146W to 152W, and QP-200 variants around 200W to 203.9W. The QP-320D and QP-320F are both 316W with 5V and 20A listed, while higher-power single-output models include QP-375-24B and QP-375-24C at 375W 24V, plus QP-375-5A through QP-375-5E at 375W to 378W with 5V variants including one listed at 30A. This model stands out in the list for combining 316W with quad output capability.
Is the QP-320F appropriate for outdoor or harsh-environment use?
The stated operating temperature is -10°C to +70°C, which supports use in a broad indoor equipment temperature range. No IP rating is listed in the provided specs, so exposed outdoor or washdown suitability cannot be confirmed from this data alone.
