Mean Well MSP-600-48 Power Supply 624W 48V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well MSP-600-48 Power Supply 624W 48V
The MSP-600 is a 600W Mean Well power converter (input range: 85~264VAC).
Key Features
- ✓ Input voltage range: 85~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 4KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ DC OK relay contact output
- ✓ Remote ON/OFF control
- ✓ Safety approvals: ISOLATION LEVEL
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesMSP Series
-
Power Rating624 Watt
-
Output Voltage48 Volt
-
Rated Current13 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~70°C
-
Warranty5 Year
-
Length8.58 in
-
Width4.13 in
-
Height2.5 in
-
Weight3.46 lb
::specification::
Frequently Asked Questions
Can I use the MSP-600-48 for a 48V industrial control or automation system?
It is built for constant-voltage 48V output and can supply up to 13A with 624W total power. That makes it a fit for 48V industrial control, automation, or embedded equipment that needs a stable 48V DC bus within those limits.
Is the MSP-600-48 suitable for 48V communications or network equipment that needs higher power?
This model provides a constant 48V output with 624W available, so it suits 48V communications or network equipment that needs more power than lower-output 48V models. Buyers should match the load to the unit's 13A maximum output current and 624W power rating.
Can the MSP-600-48 power a 48V embedded system or test bench load?
Yes, if the equipment requires constant 48V DC and stays within 13A and 624W. The wide 85-264VAC input also helps in lab, factory, or OEM environments where AC input conditions can vary.
Is the MSP-600-48 a good choice when a 48V load needs more than mid-range power capacity?
It sits above the 48V models rated at 105.6W, 206.4W, 336W, and 456W, and below the 1008W and 1608W versions in the same series. That makes it useful for 48V systems that have outgrown mid-range power supplies but do not need the highest-output MSP models.
How does the MSP-600-48 compare with the other MSP-600 voltage options?
Within the MSP-600 group, the series includes MSP-600-3.3 at 396W and 120A, MSP-600-5 at 600W and 120A, MSP-600-7.5 at 600W and 80A, MSP-600-12 at 636W and 53A, MSP-600-15 at 645W and 43A, MSP-600-24 at 648W and 27A, MSP-600-36 at 630W and 17.5A, and MSP-600-48 at 624W and 13A. The main difference is the output voltage and corresponding current rating for each model.
Can the MSP-600-48 be used in harsh temperature conditions or exposed outdoor locations?
The specified operating temperature range is -40°C to +70°C, so the temperature rating covers demanding industrial conditions. No IP rating is listed in the provided specs, so exposed outdoor or washdown use should not be assumed from this data alone.
