Mean Well QP-200D Power Supply 200W 5V 12V 24V -12V
The QP is a 100W Mean Well power converter (input range: 90~264VAC).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL60950-1, TUV EN60950-1 EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesQP Series
-
Power Rating203.4 Watt
-
Output Voltage5 Volt
-
Rated Current15 Ampere
-
Input Voltage90V~264V
-
No of Output4
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty3 Year
-
Length8.46 in
-
Width4.53 in
-
Height1.97 in
-
Weight2.65 lb
::specification::
Frequently Asked Questions
Can I use the QP-200D for industrial systems that need 5V control power and 24V field-device power together?
Yes, this model is relevant for mixed-voltage industrial electronics because it provides 5V, 12V, 24V, and -12V outputs from one constant-voltage supply. The main 5V rail is rated at 15A and the total output power is 203.4W.
Is the QP-200D a fit for embedded platforms that combine logic, analog, and higher-voltage subsystems?
It can be a strong fit when one assembly needs low-voltage logic plus higher-voltage rails in the same equipment. The combination of 5V, 12V, 24V, and -12V supports mixed digital and analog sections, and the 90-264VAC input suits standard AC-fed installations.
Would the QP-200D work in automation or instrumentation equipment that still uses a -12V rail?
Yes, the included -12V output is useful for instrumentation or interface designs that still rely on bipolar analog rails while also needing 5V, 12V, and 24V. With 203.4W total power and 5V at 15A, it is aimed at multi-rail assemblies rather than a single-voltage application.
Is this power supply intended for outdoor environments?
The available specs do not show any IP rating, so outdoor exposure should not be assumed from this product data. The stated operating temperature range is -10C to +60C, so the environment needs to remain within that range.
How does the QP-200D compare with similar QP multi-output models?
Among the nearby 200 class models, QP-200-3A is 200W with 5V and 15A, QP-200-3B is 203.4W, QP-200-3C is 203.4W, QP-200-3D is 203.9W with 5V and 10A, QP-200-3E is 203.4W, QP-200D is 203.4W with 5V and 15A, and QP-200F is 202.5W with 5V and 15A. Above that, QP-320D and QP-320F move to 316W with 5V and 20A, while the family also includes 100W, 146W, 150.2W, and 152W models plus 375W to 378W 5V and 24V units.
