Mean Well SMT01C-05 DC-DC Converter - 1W - 36~72V in 5V out
The SMT01C is a 1W Mean Well power converter (input range: 9~18Vdc).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSMT Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the SMT01C-05 to power 5V control logic from a 48V-class industrial source?
This converter is specified for a 36-72VAC input range and delivers a 5V constant-voltage output. Its 1W rating makes it appropriate for low-power logic, monitoring, or control electronics rather than higher-load 5V devices.
Is the SMT01C-05 a fit for telecom or network-adjacent embedded electronics that need a small 5V rail?
It can fit low-power embedded electronics when the available source is within the listed 36-72VAC range and the downstream circuit needs 5V constant voltage. The output capacity is 1W, so it is better suited to auxiliary electronics than primary load power.
Can this model be used in high-voltage automation systems that only need a small 5V auxiliary supply?
Yes, its input range of 36-72VAC makes it suitable where a higher-voltage supply must be converted to a small 5V rail. The converter remains a 1W device, so it should be used for light-duty interface, sensing, or control functions.
Is the SMT01C-05 suitable for outdoor equipment or only for protected enclosures?
The listed operating temperature range is -40°C to +90°C, so the temperature capability is broad. No IP rating appears in the product specs, which means the environmental data supports temperature review only and does not confirm outdoor exposure resistance.
How does the SMT01C-05 differ from the other SMT01C models?
The listed SMT01C models are all 1W converters in the same series. The SMT01C-05 is listed at 5V and 200A, while the SMT01C-12 outputs 12V at 0.08A and the SMT01C-15 outputs 15V at 0.07A.
