Mean Well SMT01C-05 DC-DC Converter - 1W - 36~72V in 5V out

SKU:
SMT01C-05

$9.13 USD
Shipping calculated at checkout.
|

Your order will be processed within 24 hours

Description

Features

SMD package with industry-standard pinout
2:1 wide input range
Operating temperature range -40~+90℃
Comply to BS EN/EN55032 radiated Class A without additional components
Optional reel packing
Protections: Short circuit(Continuous)/Overload
1.5KVDC I/O isolation
3 years warranty

General Specification

Voltage accuracy ±2.0%
Overload Protection 130~200% rated output power
Cooling Free-air convection
Short circuit protection Continuous, automatic recovery
Working temperature -40 ~ +90℃ (Refer to "Derating Curve")
EMC Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient 0.03% / ℃ (0 ~ 85℃)
Dimension (LxWxH) (mm) 15.24*10.9*7.1mm (0.6*0.43*0.28 inch)
Potting material UL 94V-0 rated

Specifications

  • Brand
    Mean Well
  • Series
    SMT Series
  • Power Rating
    1 Watt
  • Output Voltage
    5 Volt
  • Rated Current
    0.2 Ampere
  • Input Voltage
    36V~72V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CE,EMC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~90°C
  • Warranty
    3 Year
  • Length
    0.6 in
  • Width
    0.43 in
  • Height
    0.28 in
  • Weight
    0 lb

File Downloads

::specification::
