Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SMT01A-12 DC-DC Converter - 1W - 9~18V in 12V out

SKU:

SMT01A-12

$9.13 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SMD package with industry-standard pinout

2:1 wide input range

Operating temperature range -40~+90℃

Comply to BS EN/EN55032 radiated Class A without additional components

Optional reel packing

Protections: Short circuit(Continuous)/Overload

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±2.0%
Overload Protection	130~200% rated output power
Cooling	Free-air convection
Short circuit protection	Continuous, automatic recovery
Working temperature	-40 ~ +90℃ (Refer to "Derating Curve")
EMC	Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.03% / ℃ (0 ~ 85℃)
Dimension (LxWxH) (mm)	15.2410.97.1mm (0.60.430.28 inch)
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SMT Series
Power Rating

1 Watt
Output Voltage

12 Volt
Rated Current

0.08 Ampere
Input Voltage

9V~18V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.6 in
Width

0.43 in
Height

0.28 in
Weight

0 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SMT01A-12 for a low-power 12V rail in instrumentation or control electronics?

Yes, it provides constant-voltage 12V output and is rated for 1W, which suits low-power instrumentation, control, or monitoring circuits. The input range is 9~18V for systems operating in that voltage window.

Is the SMT01A-12 suitable for embedded automation hardware powered from a 12V-class source?

The 9~18V input range makes it a fit for equipment in that supply range that needs a small regulated 12V output. Because output current is 0.08A and total power is 1W, it is intended for light auxiliary loads rather than larger 12V devices.

Can this converter be used in compact industrial electronics where board space is limited?

Its package measures 15.24 x 10.9 x 7.1 mm and weighs 0.0014 kg, so it is well suited to compact board-level designs. The application should still stay within the 12V, 0.08A, and 1W output specifications.

How does SMT01A-12 compare with the other SMT01A output versions?

The SMT01A family includes SMT01A-05 at 1W, 5V, 200A; SMT01A-12 at 1W, 12V, 0.08A; and SMT01A-15 at 1W, 15V, 0.07A. This model is the 12V version for designs using a 9~18V input range.

Is the SMT01A-12 suitable for outdoor use or wide-temperature enclosures?

The converter is rated for -40C to +90C operation, so it supports a wide temperature range. However, no IP rating is listed in the provided specifications, so outdoor exposure or water-resistance should not be assumed from this data alone.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well SMT01C-15 DC-DC Converter - 1W - 36~72V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01C-12 DC-DC Converter - 1W - 36~72V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01C-05 DC-DC Converter - 1W - 36~72V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
Mean Well SMT01B-15 DC-DC Converter - 1W - 18~36V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01B-12 DC-DC Converter - 1W - 18~36V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01B-05 DC-DC Converter - 1W - 18~36V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
Mean Well SMT01A-15 DC-DC Converter - 1W - 9~18V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01A-05 DC-DC Converter - 1W - 9~18V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
