Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SMT01A-15 DC-DC Converter - 1W - 9~18V in 15V out

SKU:

SMT01A-15

$9.13 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SMD package with industry-standard pinout

2:1 wide input range

Operating temperature range -40~+90℃

Comply to BS EN/EN55032 radiated Class A without additional components

Optional reel packing

Protections: Short circuit(Continuous)/Overload

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±2.0%
Overload Protection	130~200% rated output power
Cooling	Free-air convection
Short circuit protection	Continuous, automatic recovery
Working temperature	-40 ~ +90℃ (Refer to "Derating Curve")
EMC	Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.03% / ℃ (0 ~ 85℃)
Dimension (LxWxH) (mm)	15.2410.97.1mm (0.60.430.28 inch)
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SMT Series
Power Rating

1 Watt
Output Voltage

15 Volt
Rated Current

0.06 Ampere
Input Voltage

9V~18V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.6 in
Width

0.43 in
Height

0.28 in
Weight

0 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SMT01A-15 in a 12V industrial control circuit that needs a 15V rail?

This converter is intended for applications with a 9-18VAC input and a regulated 15V constant-voltage output. Its 1W rating and 0.07A output current make it appropriate for low-power control or signal-level loads rather than larger devices.

Is the SMT01A-15 suitable for embedded boards that need a small isolated 15V supply from a 9-18VAC source?

It fits low-power embedded or interface circuits when the available source is within the listed 9-18VAC input range and the load needs 15V constant voltage. The available output is 1W total with 0.07A maximum current, so it should only be used for light auxiliary power demands.

Can this converter be used for analog or sensor interface stages that run on 15V?

It can be used where the downstream section needs a 15V constant-voltage output and the input available is 9-18VAC. Because the unit is rated at 1W and 0.07A, it is best suited to low-current analog, sensing, or signal-conditioning sections rather than higher-draw subsystems.

Is the SMT01A-15 appropriate for indoor or outdoor equipment?

The published environmental data shows an operating temperature range of -40°C to +90°C. No IP rating is listed in these specs, so the temperature range supports harsh-temperature indoor use, but the specs alone do not establish outdoor or washdown suitability.

How does the SMT01A-15 compare with the other SMT01A models?

Within the SMT01A series, all listed models are 1W converters. The SMT01A-15 provides 15V at 0.07A, the SMT01A-12 provides 12V at 0.08A, and the SMT01A-05 is listed at 5V and 200A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well SMT01C-15 DC-DC Converter - 1W - 36~72V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01C-12 DC-DC Converter - 1W - 36~72V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01C-05 DC-DC Converter - 1W - 36~72V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
Mean Well SMT01B-15 DC-DC Converter - 1W - 18~36V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01B-12 DC-DC Converter - 1W - 18~36V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01B-05 DC-DC Converter - 1W - 18~36V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
Mean Well SMT01A-12 DC-DC Converter - 1W - 9~18V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01A-05 DC-DC Converter - 1W - 9~18V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
