Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SMT01B-15 DC-DC Converter - 1W - 18~36V in 15V out

SKU:

SMT01B-15

$9.13 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SMD package with industry-standard pinout

2:1 wide input range

Operating temperature range -40~+90℃

Comply to BS EN/EN55032 radiated Class A without additional components

Optional reel packing

Protections: Short circuit(Continuous)/Overload

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±2.0%
Overload Protection	130~200% rated output power
Cooling	Free-air convection
Short circuit protection	Continuous, automatic recovery
Working temperature	-40 ~ +90℃ (Refer to "Derating Curve")
EMC	Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.03% / ℃ (0 ~ 85℃)
Dimension (LxWxH) (mm)	15.2410.97.1mm (0.60.430.28 inch)
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SMT Series
Power Rating

1 Watt
Output Voltage

15 Volt
Rated Current

0.06 Ampere
Input Voltage

18V~36V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.6 in
Width

0.43 in
Height

0.28 in
Weight

0 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SMT01B-15 to generate a 15V rail in 24V-class industrial equipment?

This model is specified for 18-36VAC input and provides a 15V constant-voltage output. With 1W total power and 0.07A output current, it is intended for low-power control, feedback, or interface sections rather than larger 15V loads.

Is the SMT01B-15 appropriate for low-power embedded or instrumentation circuits that require 15V?

It can be used where the source available is within 18-36VAC and the target circuit needs a regulated 15V output. The 1W rating limits it to small embedded or instrumentation functions with modest current demand.

Can this converter support 15V analog stages inside automation or test equipment?

Yes, it is a fit for low-power 15V constant-voltage sections when the upstream supply is 18-36VAC. The key limit is the 0.07A output current and 1W power rating, so it is aimed at light analog or signal-processing loads.

Is the SMT01B-15 suitable for indoor-only use, or can it handle wider environmental conditions?

The converter is rated for operation from -40°C to +90°C, which supports broad indoor temperature conditions. Because no IP rating is given in the listed specs, the environmental data does not establish outdoor weather exposure performance.

What is the difference between the SMT01B-15 and the other SMT01B output options?

The three listed SMT01B models all carry a 1W rating with 18-36VAC input. The SMT01B-15 outputs 15V at 0.07A, the SMT01B-12 outputs 12V at 0.08A, and the SMT01B-05 is listed at 5V and 200A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well SMT01C-15 DC-DC Converter - 1W - 36~72V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01C-12 DC-DC Converter - 1W - 36~72V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01C-05 DC-DC Converter - 1W - 36~72V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
Mean Well SMT01B-12 DC-DC Converter - 1W - 18~36V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01B-05 DC-DC Converter - 1W - 18~36V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
Mean Well SMT01A-15 DC-DC Converter - 1W - 9~18V in 15V out	1W	15V	0.06A	Indoor	$9.13	View
Mean Well SMT01A-12 DC-DC Converter - 1W - 9~18V in 12V out	1W	12V	0.08A	Indoor	$9.13	View
Mean Well SMT01A-05 DC-DC Converter - 1W - 9~18V in 5V out	1W	5V	0.2A	Indoor	$9.13	View
