Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SMT01C-12 DC-DC Converter - 1W - 36~72V in 12V out

SKU:

SMT01C-12

$9.13 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SMD package with industry-standard pinout

2:1 wide input range

Operating temperature range -40~+90℃

Comply to BS EN/EN55032 radiated Class A without additional components

Optional reel packing

Protections: Short circuit(Continuous)/Overload

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±2.0%
Overload Protection	130~200% rated output power
Cooling	Free-air convection
Short circuit protection	Continuous, automatic recovery
Working temperature	-40 ~ +90℃ (Refer to "Derating Curve")
EMC	Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.03% / ℃ (0 ~ 85℃)
Dimension (LxWxH) (mm)	15.2410.97.1mm (0.60.430.28 inch)
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SMT Series
Power Rating

1 Watt
Output Voltage

12 Volt
Rated Current

0.08 Ampere
Input Voltage

36V~72V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

0.6 in
Width

0.43 in
Height

0.28 in
Weight

0 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SMT01C-12 to provide 12V power for a small industrial control or monitoring circuit?

It can fit low-power 12V control or monitoring sections that need constant voltage output and stay within the unit's 1W capacity. The output is 12V at 0.08A, so it is suited to very light loads rather than higher-current devices.

Is the SMT01C-12 suitable for embedded electronics powered from a 36-72V bus?

Yes, this model is intended for applications where the available input is within 36-72V and the downstream circuit requires 12V constant voltage. Its small 15.24 × 10.9 × 7.1 mm package also makes it appropriate where board space is limited.

Can this converter be used in telecom or automation equipment that needs a low-power 12V rail?

It can work for low-power 12V auxiliary rails in automation or telecom electronics when the source falls within 36-72V. Because the unit is rated at 1W and 0.08A output current, it is best for light-duty support circuits rather than larger 12V loads.

Is the SMT01C-12 appropriate for harsh temperature environments?

The specified operating temperature range is -40°C to +90°C, which supports use across very cold and very hot equipment environments. Environmental sealing is not stated in the provided specs, so exposed wet or dust-heavy conditions are not defined here.

How does the SMT01C-12 compare with the other SMT01C models?

Within the SMT01C series, all listed models are 1W parts. The SMT01C-05 is 5V with 200A output current, the SMT01C-12 is 12V with 0.08A, and the SMT01C-15 is 15V with 0.07A.
