Mean Well SPBW06G-03 DC-DC Converter - 6W - 18~75V in 3.3V out
Remote ON/OFF control
3 years warranty
Key Features
- ✓SIP8 package with industry-standard pinout
- ✓4:1 wide input range
- ✓Wide operating temperature range -40~+85°C
- ✓No minimum load required
- ✓High efficiency up to 89%
- ✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓1.5KVDC I/O isolation
- ✓Remote ON/OFF control
- ✓3 years warranty
-
BrandMean Well
-
SeriesSPBW Series
-
Power Rating6 Watt
-
Output Voltage3.3 Volt
-
Rated Current1.5 Ampere
-
Input Voltage18V~75V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.86 in
-
Width0.44 in
-
Height0.36 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SPBW06G-03 to power a 3.3V embedded controller from a higher-voltage industrial input?
This model is designed for a 3.3V constant-voltage output with a 6W rating and an 18-75VAC input range. That makes it suitable for low-power embedded controllers, logic sections, or industrial electronics that need a regulated 3.3V rail from that wider input window.
Is the SPBW06G-03 a fit for 3.3V PLC interface or digital control electronics?
It can fit low-power PLC interface boards, digital control circuits, or automation logic sections that are designed around 3.3V and stay within 6W. The 1.5A output rating also aligns with compact electronics rather than larger field loads.
Can this converter be used in space-constrained automation hardware?
Yes, its dimensions are 21.8 x 11.1 x 9.2 mm and its weight is 0.0048 kg, so it is well suited to compact embedded and automation assemblies. It is intended for designs that need a small constant-voltage 3.3V converter with 18-75VAC input capability.
Is the SPBW06G-03 suitable for outdoor cabinets or wide-temperature enclosures?
The specified operating range is -40C to +85C, so the converter is rated for broad temperature conditions. The listed specs do not include an IP rating, so exposure protection for outdoor or washdown environments is not defined by this product data.
What is the difference between the SPBW06G-03 and the other SPBW06G versions?
The SPBW06G family shown here keeps the same 6W platform and changes the output rating by model. The sibling versions are SPBW06G-05 at 5V and 1.2A, SPBW06G-12 at 12V and 500A, SPBW06G-15 at 15V and 400A, while this SPBW06G-03 is 3.3V and 1.5A.
