Description
Description
Features
SIP8 package with industry-standard pinout |
4:1 wide input range |
Wide operating temperature range -40~+85°C |
No minimum load required |
High efficiency up to 89% |
Protection: Short circuit(continuous)/Overload/Input under voltage |
Comply to BS EN/EN55032 radiated Class B without additional components |
1.5KVDC I/O isolation |
Remote ON/OFF control |
3 years warranty |
General Specification
Voltage accuracy | ±1.5% |
Vibration | 10 ~ 500Hz, 2G 10min./1 cycle, the period for 60min. each along X, Y, and Z axes |
Cooling | Free-air convection |
Short circuit protection | Continuous, auto-recovery |
Working temperature | -40°C to +85°C |
EMC | Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8 |
Temp. Coefficient | 0.03% / ℃ (0 ~ 65℃) |
Dimension (LxWxH) (mm) | 21.8*9.2*11.1mm |
Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPBW Series
-
Power Rating6 Watt
-
Output Voltage3.3 Volt
-
Rated Current1.5 Ampere
-
Input Voltage9V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.86 in
-
Width0.44 in
-
Height0.36 in
-
Weight0.01 lb
