Mean Well DCWN03C-15 DC-DC Converter - 3W 36~72V DC in 15V out
Description
Description
The DCWN03C is a 3W Mean Well. power converter. and an input range of 4.5~9Vdc.
Key Features
- ✓ Input voltage range: 4.5~9Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDCWN Series
-
Power Rating3 Watt
-
Output Voltage15 Volt
-
Rated Current0.1 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the DCWN03C-15 typically used for?
The Mean Well DCWN03C-15 is typically used for isolated low-power DC-DC conversion from a 36-72V DC source to a 15V output. With 3W rated power and 0.1A output current, it fits compact electronic systems needing an isolated 15V rail from a higher-voltage input bus.
Is the DCWN03C-15 a good fit for 36-72V input systems that need 15V output?
Yes. The DCWN03C-15 is designed for 36-72V input and 15V output operation, provided the load remains within the converter's 3W and 0.1A output capacity.
Can the DCWN03C-15 be used in isolated auxiliary 15V circuits?
Yes. The converter includes 3KVDC I/O isolation, a DIP24 package, and no minimum load requirement, making it suitable for isolated low-power 15V support rails in compact electronics.
What environmental range is the DCWN03C-15 rated for?
The DCWN03C-15 is rated for -40°C to +90°C working temperature, which supports use in demanding protected electronic environments. It should still be used inside equipment or enclosure-protected systems.
How does the DCWN03C-15 compare with other DCWN03 15V variants?
The DCWN03C-15 provides 3W at 15V from a 36-72V input range. The A, B, and E versions target 9-18V, 18-36V, and 4.5-9V input ranges respectively while keeping the same general 3W 15V output class. The key distinction is the input voltage window.
