Mean Well DPBW06G-12 DC-DC Converter - 6W - 18~75V in ±12V out
Description
Description
Remote ON/OFF control
3 years warranty
Key Features
- ✓✓SIP8 package with industry-standard pinout
- ✓✓4:1 wide input range
- ✓✓Wide operating temperature range -40~+85°C
- ✓✓No minimum load required
- ✓✓High efficiency up to 89%
- ✓✓Protection: Short circuit(continuous)/Overload/Input under voltage
- ✓✓Comply to BS EN/EN55032 radiated Class B without additional components
- ✓✓1.5KVDC I/O isolation
- ✓✓Remote ON/OFF control
- ✓✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDPBW Series
-
Power Rating6 Watt
-
Output Voltage12 Volt
-
Rated Current0.25 Ampere
-
Input Voltage18V~75V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.86 in
-
Width0.44 in
-
Height0.36 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the DPBW06G-12 in a 24V or 48V industrial control cabinet?
It is intended for systems with a listed input range of 18-75V and provides a constant-voltage 12V output. With 6W total power, it fits low-power control, sensing, and interface circuits rather than larger loads.
Is the DPBW06G-12 suitable for embedded electronics that need a regulated 12V rail from a wide input range?
Yes, this model is built for a wide 18-75V input range and constant-voltage 12V output. Its 6W rating makes it a fit for compact embedded designs where the 12V rail has a modest power requirement.
Can this converter be used for low-power automation I/O or signal-conditioning circuits?
It can be used where the application needs a regulated 12V output and stays within the unit's 6W power rating. The compact 21.8 x 11.1 x 9.2 mm size also suits dense automation assemblies.
Would the DPBW06G-12 work in compact industrial or telecom boards where space is limited?
It is designed for compact installations, with dimensions of 21.8 x 11.1 x 9.2 mm and a weight of 0.0048 kg. That makes it practical for small board-level power conversion where a 12V constant-voltage output is needed.
What is the difference between the DPBW06G-05, DPBW06G-12, and DPBW06G-15?
All three models are rated at 6W. The DPBW06G-05 is 5V with 600A, the DPBW06G-12 is 12V with 250A, and the DPBW06G-15 is 15V with 200A.
Is the DPBW06G-12 suitable for outdoor or harsh-temperature environments?
Its operating temperature range is -40°C to +85°C, which supports use across a wide temperature span. No IP rating is listed in the provided specs, so the specifications do not identify it as an outdoor-rated unit.
Other DPBW06 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well DPBW06G-15 DC-DC Converter - 6W - 18~75V in ±15V out | 6W | 15V | 0.2A | Indoor | $10.33 | View |
| Mean Well DPBW06G-05 DC-DC Converter - 6W - 18~75V in ±5V out | 6W | 5V | 0.6A | Indoor | $10.39 | View |
| Mean Well DPBW06F-15 DC-DC Converter - 6W - 9~36V in ±15V out | 6W | 15V | 0.2A | Indoor | $10.33 | View |
| Mean Well DPBW06F-12 DC-DC Converter - 6W - 9~36V in ±12V out | 6W | 12V | 0.25A | Indoor | $10.33 | View |
| Mean Well DPBW06F-05 DC-DC Converter - 6W - 9~36V in ±5V out | 6W | 5V | 0.6A | Indoor | $10.33 | View |
