Mean Well EPP-150-27 Power Supply 100W 27V 3.71A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well EPP-150-27 Power Supply 100W 27V 3.71A
Overview
EPP-150-27 is the 27V output model of this series: typical efficiency 92%.
Features
- 4"x2" Compact size
- Universal AC input / Full range
- Built-in active PFC function
- High efficiency up to 93%
- Protections: Short circuit / Overload / Over voltage/ Over temperature
- 100W free air convection, 150W with 20CFM forced air
- LED indicator for power on
- No load power consumption<0.5W
- Built-in 12V/0.3A auxiliary output
- 3 years warranty
Specifications
OUTPUT
- DC VOLTAGE
- 27V
- RATED CURRENT (convection)
- 3.71A
- RATED CURRENT (20CFM FAN)
- 5.56A
- CURRENT RANGE (convection)
- 0 ~ 3.71A
- CURRENT RANGE (20CFM FAN)
- 0 ~ 5.56A
- RATED POWER (convection)
- 100.17W
- RATED POWER (20CFM FAN)
- 150.12W
- RIPPLE & NOISE (max.)Note.2
- 240mVp-p
- VOLTAGE ADJ. RANGE
- 26.46 ~ 28.35V
- VOLTAGE TOLERANCENote.3
- ±1.0%
- LINE REGULATION
- ±0.5%
- LOAD REGULATION
- ±1.0%
- SETUP, RISE TIME
- 1000ms, 30ms/230VAC 2000ms, 30ms/115VAC at full load
- HOLD UP TIME (Typ.)
- 16ms/230VAC 16ms/115VAC at full load
INPUT
- VOLTAGE RANGENote.4
- 90 ~ 264VAC 127 ~ 370VDC
- FREQUENCY RANGE
- 47 ~ 63Hz
- POWER FACTOR (Typ.)
- PF>0.95/230VAC PF>0.98/115VAC at full load
- EFFICIENCY (Typ.)
- 92%
- AC CURRENT (Typ.)
- 1.8A/115VAC 1 A/230VAC
- INRUSH CURRENT (Typ.)
- COLD START 70A/230VAC
- LEAKAGE CURRENT
- <2mA/240VAC
PROTECTION
- OVER LOAD
- 105 ~ 145% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
- OVER VOLTAGE
- 30.2 ~ 34.05V Protection type : Shut down o/p voltage, re-power on to recover
- OVER TEMPERATURE
- Protection type : Shut down o/p voltage, re-power on to recover
FUNCTION
- AUXILIARY POWER(AUX)
- 12V@0.3A for driving a fan, tolerance ± 10% at main output 100% load
ENVIRONMENT
- WORKING TEMP.
- -30 ~ +70℃ (Refer to "Derating Curve")
- WORKING HUMIDITY
- 20 ~ 90% RH non-condensing
- STORAGE TEMP., HUMIDITY
- -40 ~ +85℃, 10 ~ 95% RH
- TEMP. COEFFICIENT
- ±0.03%/℃ (0 ~ 45℃)
- OPERATING ALTITUDENote.5
- 2000 meters
- VIBRATION
- 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY & EMC (Note 6)
- SAFETY STANDARDS
- UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
- WITHSTAND VOLTAGE
- I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
- ISOLATION RESISTANCE
- I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC/ 500VDC / 25℃/ 70% RH
- EMC EMISSION
- Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
- EMC IMMUNITY
- Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, heavy industry level, EAC TP TC 020
OTHERS
- MTBF
- 2002.2K hrs min. Telcordia SR-332 (Bellcore) ; 207.1K hrs min. MIL-HDBK-217F (25℃)
- DIMENSION
- 101.6*50.8*29mm (L*W*H)
- PACKING
- 0.2Kg; 72pcs/15.4Kg/0.82CUFT
Test conditions and notes6
- 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
- 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
- 3. Tolerance : includes set up tolerance, line regulation and load regulation.
- 4. Derating may be needed under low input voltages. Please check the derating curve for more details.
- 5. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
- 6. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
Technical drawings
Downloads
Datasheet1
Certificates8
Test reports1
Catalogues1
FAQ
Can I use the EPP-150-27 for 27V factory automation equipment?
Yes, if the automation device requires a constant 27V DC supply and the load stays within 3.71A and 100.17W. That makes it suitable for moderate-power 27V control applications rather than higher-draw 27V systems.
Is this model appropriate for 27V embedded or OEM systems?
It can be used in embedded equipment that is designed for constant 27V input. The rated output is 27V at up to 3.71A, and the input range is 90-264VAC.
Can the EPP-150-27 power 27V instrumentation or test equipment?
Yes, for 27V electronic equipment that remains within the 100.17W power limit. Buyers should confirm both voltage compatibility and that continuous current draw does not exceed 3.71A.
What should I check before pairing this supply with a 27V load?
The load needs to match a constant 27V output and stay at or below 3.71A and 100.17W under convection cooling. If the application requires more current at 27V, the unit is rated for up to 5.56A and 150.12W with 20CFM forced-air cooling.
Is the EPP-150-27 suitable for outdoor installations?
The operating temperature range is -30°C to +70°C, with output derating at higher temperatures per the derating curve, but the provided specs do not include an IP rating. That supports use in protected indoor equipment rather than direct outdoor exposure.
