Mean Well MDD02M-05 DC-DC Converter - 2W - 10.8~13.2V in ±5V out
The MDD02M is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 6KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL60601-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesMDD Series
-
Power Rating2 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EAC,EMC,LVD,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.49 in
-
Height0.39 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the MDD02M-05 in a 12V-class embedded system that needs ±5V rails?
Yes, this model is designed for a 10.8~13.2V input and provides ±5V constant-voltage output. Its 2W rating makes it suitable for low-power embedded analog sections, interface boards, and isolated signal-conditioning circuits.
Is the MDD02M-05 suitable for industrial control electronics powered from a 12V nominal rail?
It is a match when the available source falls within 10.8~13.2V and the downstream circuit needs ±5V rails. The converter is rated at 2W and comes in a 19.5 × 12.5 × 9.8 mm package for compact PCB-level integration.
Can this converter be used on automation or instrumentation boards with tight space limits?
Yes, the 19.5 × 12.5 × 9.8 mm dimensions and 0.0042 kg weight make it practical for dense automation or instrumentation boards. It is intended for constant-voltage conversion from 10.8~13.2V input to ±5V output at 2W.
Is the MDD02M-05 intended for outdoor equipment or harsh environments?
The operating temperature range is -40°C to +85°C, so the thermal specification is broad. The provided specs do not list an IP rating, which means outdoor or exposed-environment suitability is not stated here.
How does the MDD02M-05 compare with other MDD02M series models?
The MDD02M-05 is listed at 2W with 5V output and 200A output current. Other listed siblings are MDD02M-05N at 2W, 5V, 25A; MDD02M-09 at 2W, 9V, 111A; MDD02M-12 at 2W, 12V, 0.08A; MDD02M-12N at 2W, 12V, 25A; MDD02M-15 at 2W, 15V, 0.07A; and MDD02M-15N at 2W, 15V, 25A.
