Mean Well HVGC-65-1050B Power Supply 65W 1050mA - Dimmable
The HVGC-65 is a 65W Mean Well DIN rail power converter with a 189mm profile (input range: 180~528VAC).
Key Features
- ✓ 189mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~528VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384, independent, EAC TP TC 004 IP65 or IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVGC Series
-
Power Rating65.1 Watt
-
Output Voltage62 Volt
-
Rated Current1.05 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CE,EAC,ENEC,FCC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~80°C
-
Warranty5 Year
-
Length7.44 in
-
Width2.42 in
-
Height1.45 in
-
Weight1.7 lb
::specification::
Frequently Asked Questions
Can the HVGC-65-1050B run a constant current LED downlight outdoors?
Yes, if the downlight needs 1050mA constant current and the total LED forward voltage is within the 6-62V CC range. Its IP67 waterproof rating makes it better suited to wet or exposed locations than indoor-only drivers. It is still a constant current driver, not a 12V or 24V constant voltage supply.
Is this a good fit for exterior signage LED modules?
It can be used for exterior signage assemblies when the modules are constant current at 1050mA and the total forward voltage falls between 6V and 62V. Many signage modules are constant voltage, so those are not compatible. The IP67 enclosure is appropriate where weather resistance is required.
Can I use this driver for a small 1050mA LED array in a damp or washdown area?
Yes, provided the LED array is a constant current load at 1050mA and its total forward voltage stays within 6-62V. The IP67 waterproof rating supports harsher moisture exposure than IP65 water-resistant versions. Its output is limited to 65.1W, so the array must stay within that electrical envelope.
What should I check before pairing the HVGC-65-1050B with LEDs?
Check that the LEDs require 1050mA constant current and that the full series load operates within the 6-62V constant current range. The number of LEDs depends on each LED's forward voltage, so there is no fixed LED count. This driver is not intended for constant voltage LED strips or modules.
Is IP67 the main reason to choose the HVGC-65-1050B over the HVGC-65-1050AB?
For environmental exposure, yes: the HVGC-65-1050B is IP67 waterproof, while the HVGC-65-1050AB is IP65 water-resistant. Electrically, both are 65.1W, 1050mA constant current drivers with a 6-62V CC range and 180-528VAC input. That means the main difference is enclosure rating rather than output rating.
