Mean Well HVGC-65-350AB Power Supply 65W 350mA - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HVGC-65-350AB Power Supply 65W 350mA - Adjustable and Dim...
The HVGC-65 is a 65W Mean Well DIN rail power converter with a 189mm profile (input range: 180~528VAC).
Key Features
- ✓ 189mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~528VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384, independent, EAC TP TC 004 IP65 or IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVGC Series
-
Power Rating65.1 Watt
-
Output Voltage186 Volt
-
Rated Current0.35 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Built-in Potentiometer,Resistance
-
Standards MetCB,CE,EAC,ENEC,FCC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~80°C
-
Warranty5 Year
-
Length7.44 in
-
Width2.42 in
-
Height1.45 in
-
Weight1.7 lb
::specification::
Frequently Asked Questions
Can I use the HVGC-65-350AB for a commercial LED downlight that runs at 350mA?
Yes, if the fixture is a constant current 350mA load and its total LED forward voltage is within the 18-186V CC range. That range is useful for higher-voltage series downlight engines. It should not be used with constant voltage LED products.
Is this model suitable for narrow-beam or accent fixtures built from small LED arrays?
It can be, when the array is designed for 350mA constant current and the combined forward voltage falls between 18V and 186V. The exact LED quantity depends on the forward voltage of each LED, not on a fixed count. With 65.1W output, it is intended for constant current arrays within that voltage window.
Can the HVGC-65-350AB power signage lighting that uses constant current modules?
Yes, for signage assemblies using constant current 350mA modules where the total series voltage stays in the 18-186V range. It is not the right choice for standard constant voltage signage modules. Because it is IP65 water-resistant, it suits locations where limited environmental sealing is needed.
What LEDs are compatible with the HVGC-65-350AB?
Compatible loads are constant current LEDs rated for 350mA, with a total forward voltage inside the 18-186V CC output range. The number of LEDs depends on each LED's forward voltage, so the correct check is total series voltage rather than LED count. Constant voltage strips and modules are not compatible with this driver type.
Can the HVGC-65-350AB be used in hot or cold outdoor equipment areas?
It is rated for operation from -40°C to +80°C, so it is intended for a wide ambient temperature range. Its IP65 water-resistant housing and aluminium casing support use in demanding indoor or sheltered outdoor environments. For applications requiring a fully waterproof enclosure, the IP67 B version may be the closer match.
