Mean Well HVGC-65-1050A Power Supply 65W 1050mA - Adjustable
The HVGC-65 is a 65W Mean Well DIN rail power converter with a 189mm profile (input range: 180~528VAC).
Key Features
- ✓ 189mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~528VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384, independent, EAC TP TC 004 IP65 or IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVGC Series
-
Power Rating65.1 Watt
-
Output Voltage62 Volt
-
Rated Current1.05 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming ControlBuilt-in Potentiometer
-
Standards MetCB,CE,EAC,ENEC,FCC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~80°C
-
Warranty5 Year
-
Length7.44 in
-
Width2.42 in
-
Height1.45 in
-
Weight1.7 lb
::specification::
Frequently Asked Questions
Can I use the HVGC-65-1050A for a compact LED downlight?
Yes, it can suit compact constant current LED downlights that require 1050mA and operate within the 6-62V CC range. Its 65.1W output is aimed at smaller fixtures rather than large high-power arrays. It should only be used where the downlight is designed for constant current input.
Is the HVGC-65-1050A suitable for small LED signage modules?
It can be a fit for smaller signage modules or channel-style LED assemblies that need 1050mA constant current and fall within 6-62V. The IP65 water-resistant housing supports use in damp or semi-exposed locations. It is not intended for constant voltage signage products.
Can this driver power a small LED array for architectural lighting?
Yes, this model is appropriate for small constant current LED arrays that need 1050mA and a relatively low total forward voltage within 6-62V. Its 65.1W rating makes it a smaller-series option compared with the higher-power HVGC drivers. That makes it more suitable for compact lighting loads than large arrays.
How do I check whether my LEDs are compatible with the HVGC-65-1050A?
The LED load must be designed for 1050mA constant current, and the total LED forward voltage must stay within the 6-62V constant current range. The number of LEDs depends on the forward voltage of each LED, so there is no single stated LED count. This is a constant current driver, not a constant voltage power supply.
Can the HVGC-65-1050A be used in outdoor or difficult environments?
It is rated IP65 water-resistant and has an operating temperature range of -40°C to +80°C, which supports use in demanding conditions. The aluminium casing also helps for tougher commercial lighting environments. Its wide 180-528VAC input range makes it flexible across different AC supply conditions.
