Mean Well SKE15B-05 DC-DC Converter - 15W - 18~36V in 5V out 3A
The SKE15B is a 15W Mean Well power converter.
Key Features
- ✓ 1KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKE Series
-
Power Rating15 Watt
-
Output Voltage5 Volt
-
Rated Current3 Ampere
-
Input Voltage18V~36V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~71°C
-
Warranty2 Year
-
Length2 in
-
Width2 in
-
Height0.43 in
-
Weight0.14 lb
::specification::
Frequently Asked Questions
Can I use the SKE15B-05 to power a 5V industrial controller or embedded board from an 18-36VAC source?
Yes. This model accepts 18-36VAC input and provides a constant 5V output at up to 3A, with 15W total power. That makes it appropriate for 5V industrial logic boards, embedded controllers, and similar low-voltage electronics that need regulated constant-voltage output.
Is the SKE15B-05 suitable for 5V automation sensors or communication modules in a control cabinet?
It can be a fit for 5V automation electronics when the load stays within 5V, 3A, and 15W. The constant-voltage output is intended for equipment that expects a regulated 5V supply rather than a current-driven source.
Can this converter be used for 5V HMI accessories or panel electronics in industrial equipment?
Yes, if the accessory requires a regulated 5V supply and its demand is within 3A and 15W. Its 18-36VAC input range also suits systems where that AC range is already available inside the equipment.
Is the SKE15B-05 a good choice for compact 5V embedded systems where board space matters?
It is suited to compact designs because the unit measures 50.8 × 50.8 × 11.0 mm and weighs 0.065 kg. Those dimensions make it easier to use in space-constrained industrial or embedded assemblies that need 5V constant-voltage output.
What is the difference between the SKE15B-05 and the other SKE15B output options?
All SKE15B models in this group are 15W converters with 18-36VAC input, the same 50.8 × 50.8 × 11.0 mm size, and the same -25°C to +71°C operating range. The difference is output: the SKE15B-05 is 5V at 3A, the SKE15B-12 is 12V at 1.25A, the SKE15B-15 is 15V at 1A, and the SKE15B-24 is 24V at 625A.
Can the SKE15B-05 be used in cold or hot industrial environments?
It is rated for operation from -25°C to +71°C. That supports use in many indoor industrial environments across a fairly wide temperature span, provided the application stays within that published operating range.
