Mean Well SPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out
The SPUN02L is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSPUN Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.13 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~105°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SPUN02L-15 to generate 15V for a low-power industrial sensor board?
Yes, it is a constant-voltage DC-DC converter with a 15V output and a 2W power rating, which fits low-power sensor and interface electronics. Its small 19.6 × 10.2 × 7.2 mm package also suits compact industrial or embedded boards where space is limited.
Is the SPUN02L-15 suitable for embedded control circuits that need a regulated 15V rail?
It can fit embedded control designs that need a regulated 15V output within a 2W budget. The specified input range is 4.5~5.5V in, so it is intended for designs built around that low-voltage input window.
Can this converter be used in compact automation electronics with very limited board space?
Yes, the module is physically small at 19.6 × 10.2 × 7.2 mm and weighs 0.0027 kg, so it is suited to dense automation or instrumentation assemblies. Its constant-voltage 15V output is better matched to low-power control electronics than to larger 15V loads.
Is the SPUN02L-15 appropriate for outdoor or harsh-environment equipment?
The operating temperature range is -40°C to +105°C, which supports wide-temperature industrial use. No IP rating is listed in the provided specs, so it should not be treated as an outdoor- or washdown-rated part based on these specs alone.
How does the SPUN02L-15 compare with the other SPUN02L models?
The SPUN02L family shown here includes three 2W models: SPUN02L-05 with 5V output and 400A output current, SPUN02L-12 with 12V output and 167A output current, and SPUN02L-15 with 15V output and 134A output current. They are sibling versions in the same 2W series, with the main differences being output voltage and listed output current.
