Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SPUN02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out

SKU:

SPUN02N-12

$4.67 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP7 package with industry-standard pinout

Wide operating temperature range -40~+105°C

High efficiency up to 87%

Comply to BS EN/EN55032 radiated Class A without additional components

Low cost

Protection: Short circuit(continuous)/Overload

3KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, Z axes
Cooling	Free-air convection
Short circuit protection	Continuous, auto-recovery
Working temperature	-40°C to +105°C
EMC	Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	±0.05% / °C
Dimension (LxWxH) (mm)	19.6x7.2x10.2mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SPUN Series
Power Rating

2 Watt
Output Voltage

12 Volt
Rated Current

0.16 Ampere
Input Voltage

21.6V~26.4V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~105°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SPUN02N-12 to power a 12V sensor or interface board in industrial equipment?

Yes, this converter is suited to low-power 12V loads such as sensors, interface boards, and embedded control circuits that need constant-voltage output. It provides 12V output at 2W and accepts a listed 21-26VAC input range.

Is the SPUN02N-12 appropriate for embedded or automation electronics with very limited board space?

It is designed for compact electronics where space and weight matter. The module measures 19.6 × 10.2 × 7.2 mm and weighs 0.0027 kg, which fits small embedded and automation assemblies better than larger chassis supplies.

Can this 12V DC-DC converter be used for low-power monitoring or control circuits in a 24V-class system?

It can be used where the source falls within the listed 21-26VAC input range and the downstream device needs a regulated 12V constant-voltage output. With a 2W rating, it is intended for low-power control, monitoring, and signal electronics rather than larger loads.

Would the SPUN02N-12 fit instrumentation or communications subcircuits that need stable 12V output?

Yes, it is a match for small instrumentation or communications subcircuits that require 12V constant voltage from a listed 21-26VAC source. Its 2W capacity makes it appropriate for light auxiliary electronics, not high-power equipment.

Is the SPUN02N-12 suitable for outdoor or harsh-temperature environments?

The operating temperature range is -40°C to +105°C, so it is specified for wide temperature conditions. However, no IP rating is listed, so the specs do not indicate protection for direct outdoor exposure, water, or dust without an enclosure.

How does the SPUN02N-12 compare with the other SPUN02N models?

Within the sibling group, all listed models are 2W converters. The SPUN02N-05 is 5V and 400A, the SPUN02N-12 is 12V and 167A, and the SPUN02N-15 is 15V and 134A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well SPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
Mean Well SPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
Mean Well SPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
