Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out

SKU:

SPUN02L-15

$4.67 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP7 package with industry-standard pinout

Wide operating temperature range -40~+105°C

High efficiency up to 87%

Comply to BS EN/EN55032 radiated Class A without additional components

Low cost

Protection: Short circuit(continuous)/Overload

3KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, Z axes
Cooling	Free-air convection
Short circuit protection	Continuous, auto-recovery
Working temperature	-40°C to +105°C
EMC	Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	±0.05% / °C
Dimension (LxWxH) (mm)	19.6x7.2x10.2mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SPUN Series
Power Rating

2 Watt
Output Voltage

15 Volt
Rated Current

0.13 Ampere
Input Voltage

4.5V~5.5V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~105°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SPUN02L-15 to generate 15V for a low-power industrial sensor board?

Yes, it is a constant-voltage DC-DC converter with a 15V output and a 2W power rating, which fits low-power sensor and interface electronics. Its small 19.6 × 10.2 × 7.2 mm package also suits compact industrial or embedded boards where space is limited.

Is the SPUN02L-15 suitable for embedded control circuits that need a regulated 15V rail?

It can fit embedded control designs that need a regulated 15V output within a 2W budget. The specified input range is 4.5~5.5V in, so it is intended for designs built around that low-voltage input window.

Can this converter be used in compact automation electronics with very limited board space?

Yes, the module is physically small at 19.6 × 10.2 × 7.2 mm and weighs 0.0027 kg, so it is suited to dense automation or instrumentation assemblies. Its constant-voltage 15V output is better matched to low-power control electronics than to larger 15V loads.

Is the SPUN02L-15 appropriate for outdoor or harsh-environment equipment?

The operating temperature range is -40°C to +105°C, which supports wide-temperature industrial use. No IP rating is listed in the provided specs, so it should not be treated as an outdoor- or washdown-rated part based on these specs alone.

How does the SPUN02L-15 compare with the other SPUN02L models?

The SPUN02L family shown here includes three 2W models: SPUN02L-05 with 5V output and 400A output current, SPUN02L-12 with 12V output and 167A output current, and SPUN02L-15 with 15V output and 134A output current. They are sibling versions in the same 2W series, with the main differences being output voltage and listed output current.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well SPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
Mean Well SPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
Mean Well SPUN02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
