Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out

SKU:

SPUN02M-15

$4.67 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP7 package with industry-standard pinout

Wide operating temperature range -40~+105°C

High efficiency up to 87%

Comply to BS EN/EN55032 radiated Class A without additional components

Low cost

Protection: Short circuit(continuous)/Overload

3KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, Z axes
Cooling	Free-air convection
Short circuit protection	Continuous, auto-recovery
Working temperature	-40°C to +105°C
EMC	Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	±0.05% / °C
Dimension (LxWxH) (mm)	19.6x7.2x10.2mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SPUN Series
Power Rating

2 Watt
Output Voltage

15 Volt
Rated Current

0.13 Ampere
Input Voltage

10.8V~13.2V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~105°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SPUN02M-15 to create a 15V rail for low-power automation electronics from a 10.8~13.2V source?

Yes, that is the kind of conversion this model is specified for: 10.8~13.2V input to a constant 15V output. With a 2W rating, it is intended for low-power automation, sensing, or control electronics rather than larger 15V loads.

Is the SPUN02M-15 suitable for compact embedded boards that need 15V output?

It can be a fit for compact embedded boards because the module measures 19.6 × 10.2 × 7.2 mm and weighs 0.0027 kg. The output is fixed at 15V constant voltage, with a total power rating of 2W.

Can this model be used for low-power industrial analog or interface circuits that require 15V?

Yes, it is appropriate for low-power 15V analog or interface circuits as long as the application stays within its 2W rating. The specified 10.8~13.2V input range makes it relevant for systems designed around that source window.

Is the SPUN02M-15 meant for outdoor industrial environments?

The operating temperature spec of -40°C to +105°C supports wide-temperature operation. However, no IP rating is listed, so the provided specs do not establish outdoor or direct-exposure suitability.

What are the main differences between SPUN02M-15 and the other SPUN02M models?

The listed SPUN02M siblings are all 2W converters, but they are offered in different outputs. SPUN02M-05 is 5V with 400A output current, SPUN02M-12 is 12V with 167A, and SPUN02M-15 is 15V with 134A.
