Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out

SKU:

SPUN02N-15

$4.67 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP7 package with industry-standard pinout

Wide operating temperature range -40~+105°C

High efficiency up to 87%

Comply to BS EN/EN55032 radiated Class A without additional components

Low cost

Protection: Short circuit(continuous)/Overload

3KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, Z axes
Cooling	Free-air convection
Short circuit protection	Continuous, auto-recovery
Working temperature	-40°C to +105°C
EMC	Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	±0.05% / °C
Dimension (LxWxH) (mm)	19.6x7.2x10.2mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SPUN Series
Power Rating

2 Watt
Output Voltage

15 Volt
Rated Current

0.13 Ampere
Input Voltage

21.6V~26.4V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~105°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SPUN02N-15 for a 15V analog or measurement circuit inside industrial equipment?

Yes, it fits low-power 15V analog, measurement, and signal-conditioning circuits that need constant-voltage output. The converter is rated for 2W and accepts a listed 21-26VAC input range.

Is this 15V converter a good choice for embedded controller daughterboards or compact automation modules?

It is well suited to compact electronics because the body is only 19.6 × 10.2 × 7.2 mm and the weight is 0.0027 kg. That makes it practical for small embedded boards and tightly packed automation modules that need 15V output.

Can the SPUN02N-15 be used as an auxiliary 15V rail for low-power industrial controls?

Yes, it can serve as a small auxiliary supply where the source is within the listed 21-26VAC range and the load needs 15V constant voltage. Its 2W rating keeps it in the low-power category for controls, instrumentation, and embedded support circuits.

Would this model work for isolated low-power electronics in automation or telecom assemblies that require 15V?

It is appropriate for low-power electronics that specifically require 15V output and do not exceed the converter's 2W rating. The listed input range is 21-26VAC, so it is intended for systems built around that source range.

Can the SPUN02N-15 be used in outdoor equipment cabinets or wide-temperature installations?

The specified operating range is -40°C to +105°C, which supports wide-temperature applications. No IP rating is provided in the specs, so the product data does not indicate direct exposure suitability for rain, washdown, or open outdoor mounting.

What is the difference between the SPUN02N-15 and the other SPUN02N versions?

All listed siblings are 2W models, but they differ in output voltage and current. The SPUN02N-05 is 5V and 400A, the SPUN02N-12 is 12V and 167A, and the SPUN02N-15 is 15V and 134A.
