Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SPUN02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out

SKU:

SPUN02N-05

$4.67 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

SIP7 package with industry-standard pinout

Wide operating temperature range -40~+105°C

High efficiency up to 87%

Comply to BS EN/EN55032 radiated Class A without additional components

Low cost

Protection: Short circuit(continuous)/Overload

3KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±3%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, Z axes
Cooling	Free-air convection
Short circuit protection	Continuous, auto-recovery
Working temperature	-40°C to +105°C
EMC	Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	±0.05% / °C
Dimension (LxWxH) (mm)	19.6x7.2x10.2mm
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

SPUN Series
Power Rating

2 Watt
Output Voltage

5 Volt
Rated Current

0.4 Ampere
Input Voltage

21.6V~26.4V
No of Output

1
Dimming Control

None
Standards Met

CE,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~105°C
Warranty

3 Year
Length

0.77 in
Width

0.4 in
Height

0.28 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the SPUN02N-05 to step down a 21.6~26.4V source to 5V for industrial electronics?

Yes, this converter is specified for 21.6~26.4V input and delivers a constant 5V output at 2W. That makes it suitable for low-power industrial electronics, control interfaces, and embedded boards that need 5V from a higher-voltage source.

Is the SPUN02N-05 appropriate for 24V-style automation systems that need a low-power 5V rail?

It is aligned with that use case because the input range is 21.6~26.4V and the output is 5V constant voltage. The 2W rating means it fits low-power logic, monitoring, and interface functions rather than larger 5V loads.

Can this converter be used on compact monitoring or embedded control boards?

Yes, the module is small at 19.6 × 10.2 × 7.2 mm and weighs 0.0027 kg, which helps in compact board-level designs. Its regulated 5V output is appropriate for low-power embedded and monitoring electronics within the 2W limit.

Is the SPUN02N-05 suitable for outdoor cabinets or only protected enclosures?

The operating temperature range is -40°C to +105°C, so the temperature spec supports demanding conditions in protected equipment. No IP rating is listed, so these specs do not indicate suitability for exposed outdoor use.

How does the SPUN02N-05 compare with the other SPUN02N models?

The SPUN02N series entries listed here are all 2W models with different outputs. SPUN02N-05 is 5V with 400A output current, SPUN02N-12 is 12V with 167A, and SPUN02N-15 is 15V with 134A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well SPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
Mean Well SPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out	2W	15V	0.13A	Indoor	$4.67	View
Mean Well SPUN02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out	2W	12V	0.16A	Indoor	$4.67	View
Mean Well SPUN02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out	2W	5V	0.4A	Indoor	$4.67	View
