Mean Well SPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out
The SPUN02M is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSPUN Series
-
Power Rating2 Watt
-
Output Voltage5 Volt
-
Rated Current0.4 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~105°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SPUN02M-05 to derive 5V for a PLC accessory or logic interface from a 10.8~13.2V source?
Yes, this model is built for 10.8~13.2V input and provides a constant 5V output at 2W. That makes it a fit for low-power PLC accessory boards, logic interfaces, and similar control electronics that need a regulated 5V rail.
Is the SPUN02M-05 a good fit for embedded 12V-system electronics that need 5V power?
It is intended for that kind of voltage conversion because the specified input range is 10.8~13.2V in and the output is 5V constant voltage. The 2W rating means it is aligned with low-power embedded electronics rather than higher-power 5V devices.
Can this model be used in low-power industrial monitoring or automation boards?
Yes, the 5V constant-voltage output and 2W power rating suit compact monitoring, control, and embedded automation boards. Its 19.6 × 10.2 × 7.2 mm size is also useful where PCB area is tight.
Is the SPUN02M-05 suitable for indoor panels versus exposed outdoor equipment?
Its operating temperature range is -40°C to +105°C, so the temperature spec supports demanding indoor industrial environments. No IP rating is provided, so these specs do not support treating it as an exposed outdoor-rated converter.
What is the difference between the SPUN02M-05 and the other SPUN02M versions?
All three listed SPUN02M models are 2W converters in the same series. The outputs differ by model: SPUN02M-05 is 5V with 400A output current, SPUN02M-12 is 12V with 167A, and SPUN02M-15 is 15V with 134A.
