Mean Well SPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out
The SPUN02N is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSPUN Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.13 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~105°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the SPUN02N-15 for a 15V analog or measurement circuit inside industrial equipment?
Yes, it fits low-power 15V analog, measurement, and signal-conditioning circuits that need constant-voltage output. The converter is rated for 2W and accepts a listed 21-26VAC input range.
Is this 15V converter a good choice for embedded controller daughterboards or compact automation modules?
It is well suited to compact electronics because the body is only 19.6 × 10.2 × 7.2 mm and the weight is 0.0027 kg. That makes it practical for small embedded boards and tightly packed automation modules that need 15V output.
Can the SPUN02N-15 be used as an auxiliary 15V rail for low-power industrial controls?
Yes, it can serve as a small auxiliary supply where the source is within the listed 21-26VAC range and the load needs 15V constant voltage. Its 2W rating keeps it in the low-power category for controls, instrumentation, and embedded support circuits.
Would this model work for isolated low-power electronics in automation or telecom assemblies that require 15V?
It is appropriate for low-power electronics that specifically require 15V output and do not exceed the converter's 2W rating. The listed input range is 21-26VAC, so it is intended for systems built around that source range.
Can the SPUN02N-15 be used in outdoor equipment cabinets or wide-temperature installations?
The specified operating range is -40°C to +105°C, which supports wide-temperature applications. No IP rating is provided in the specs, so the product data does not indicate direct exposure suitability for rain, washdown, or open outdoor mounting.
What is the difference between the SPUN02N-15 and the other SPUN02N versions?
All listed siblings are 2W models, but they differ in output voltage and current. The SPUN02N-05 is 5V and 400A, the SPUN02N-12 is 12V and 167A, and the SPUN02N-15 is 15V and 134A.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SPUN02 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well SPUN02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out | 2W | 12V | 0.16A | Indoor | $4.67 | View |
| Mean Well SPUN02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out | 2W | 5V | 0.4A | Indoor | $4.67 | View |
| Mean Well SPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out | 2W | 15V | 0.13A | Indoor | $4.67 | View |
| Mean Well SPUN02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out | 2W | 12V | 0.16A | Indoor | $4.67 | View |
| Mean Well SPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out | 2W | 5V | 0.4A | Indoor | $4.67 | View |
| Mean Well SPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out | 2W | 15V | 0.13A | Indoor | $4.67 | View |
| Mean Well SPUN02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out | 2W | 12V | 0.16A | Indoor | $4.67 | View |
| Mean Well SPUN02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out | 2W | 5V | 0.4A | Indoor | $4.67 | View |
