Mean Well GC160A48-AD1 Portable Chargers 160.5W 54.4V 2.95A - Green Adaptor
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well GC160A48-AD1 Portable Chargers 160.5W 54.4V 2.95A - Green...
The GC160A48 is a 160W Mean Well power converter.
Key Features
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Safety approvals: EN62368-1 , EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesGC Series
-
Power Rating160.5 Watt
-
Output Voltage54.4 Volt
-
Rated Current2.95 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.89 in
-
Width2.83 in
-
Height1.38 in
-
Weight1.54 lb
::specification::
Frequently Asked Questions
What is the main use case for the Mean Well GC160A48-AD1?
The GC160A48-AD1 is a portable AC/DC charger and power supply designed for applications that require 54.4V DC output at up to 2.95A. It is suited to OEM, industrial, and commercial use where a compact external charger with built-in protections is needed.
What are the output ratings of this charger?
This model is rated for 160.5W total output power. Its nominal output is 54.4V DC with a rated current of 2.95A, making it appropriate for equipment or charging applications matched to those electrical requirements.
What input power range does the GC160A48-AD1 support?
The charger accepts a universal AC input range of 85 to 264VAC, as well as 120 to 370VDC. That wide input range makes it practical for use across different regions and power environments without needing a separate input selector.
What protection features are included in this model?
The GC160A48-AD1 includes protection for short circuit, overload, over voltage, and over temperature conditions. Overload protection operates at 90 to 110% constant current with auto-recovery, while over-voltage protection shuts down output and recovers after re-powering.
Can this charger be used in demanding temperature environments?
This model has a working temperature range of -30°C to +70°C, subject to the manufacturer's derating curve. That makes it suitable for many industrial and mobile environments where ambient conditions can vary significantly.
How efficient is the Mean Well GC160A48-AD1?
The charger is rated for efficiency up to 94%, which helps reduce wasted energy and heat generation during operation. It also has no-load power consumption below 1W, which is useful where standby energy use matters.
What physical format and interface style does this charger use?
The GC160A48-AD1 comes in a fully enclosed plastic case measuring 175 x 72 x 35 mm and weighs 0.7 kg. It uses a 3-pole IEC320-C14 AC inlet and includes a 120 cm output cable with a standard Power DIN 4P lock-type DC plug.
How can users check the charging status on this model?
This charger includes a 2-color LED indicator for charging status. That gives users a simple visual way to monitor operating state without needing external metering for basic status checks.
