Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well GC160A48-R7B Portable Chargers 160.5W 54.4V 2.95A - Green Adaptor
class I power, no load power consumption < 1.0W, 2 stage charging
SKU:
GC160A48-R7B
$48.02 USD
Unit price /
Unavailable
Shipping calculated at checkout.
|
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well GC160A48-R7B Portable Chargers 160.5W 54.4V 2.95A - Green...
$48.02 USD
Unit price /
Unavailable
Description
Description
Features
| Universal AC input / Full range |
| Built-in active PFC function |
| Protections: Short circuit / Overload / Over voltage / Over Temp. |
| No load power consumption < 1W |
| High efficiency up to 94% |
| 2 stage charging characteristic |
| Cooling by free air convection |
| 3 pole AC inlet IEC320-C14 |
| Class I power (with earth pin) |
| Fully enclosed plastic case |
| 2 color LED indicator for charging status |
| 2 years warranty |
General Specification
| AC input voltage range | 85~264VAC; 120~370VDC |
| Overload protection | 90~110% constant current, auto-recovery |
| Over voltage protection | 105%~135% shut down O/P voltage, re-power on to recover |
| Withstand voltage | I/P-O/P: 3kVAC |
| Working temperature | -30~+70°C (refer to derating curve) |
| Safety standards | UL1012 (GC120Axx-AD1 only), EN60950-1 approved |
| EMC standards | EN55022 class B, FCC part 15 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 |
| Dimension (LxWxH) | 175x 72x 35 mm |
| Length of output cable | 120cm of UL2464, 18AWGx 4C |
| Standard DC plug | Power DIN 4P with lock type (R7B) |
Specifications
Specifications
-
BrandMean Well
-
SeriesGC Series
-
Power Rating160.5 Watt
-
Output Voltage54.4 Volt
-
Rated Current2.95 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,FCC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.89 in
-
Width2.83 in
-
Height1.38 in
-
Weight1.54 lb
File Downloads
File Downloads
::specification::
