Mean Well HBG-160-60A Power Supply 160W 60V - Adjustable 2.6A

Name: Mean Well HBG-160-60A Power Supply 160W 60V - Adjustable 2.6A
Brand: Mean Well
SKU: HBG-160-60A
Price: 52.25 USD
Availability: InStock

circular shapefor high/low bay lightmetal case for 100W+

SKU HBG-160-60A

$52.25 USD ~~$60.58~~

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The HBG-160-60A is a 156W Mean Well AC-DC LED driver (input: 90~305VAC, output: 60V, operating temperature: -40~+85°C).

Key Features

✓ Input voltage: 90~305VAC
✓ Output voltage: 60V
✓ Rated output current: 2.6A
✓ Ingress protection: IP65
✓ Operating temperature: -40~+85°C
✓ Safety certifications: CB, CCC, CE, EAC, ENEC, UL
✓ 5 year warranty

Brand

Mean Well
Series

HBG Series
Power Rating

156 Watt
Output Voltage

60 Volt
Rated Current

2.6 Ampere
Input Voltage

90V~305V
No of Output

1
Dimming Control

Built-in Potentiometer
Standards Met

CB,CCC,CE,EAC,ENEC,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~85°C
Warranty

5 Year
Length

5.97 in
Width

5.97 in
Height

2.62 in
Weight

3.37 lb

Frequently Asked Questions

Can the HBG-160-60A be used for a 60V low bay or high bay retrofit?

Yes, the feature set specifically lists high/low bay light use, and this model is a constant current driver with a 36-60V range. It delivers 156W at 2.6A, which fits higher-power 60V fixture designs.

Is the HBG-160-60A suitable for sheltered outdoor 60V lighting?

It can be used in outdoor lighting applications where IP65 water resistance is sufficient and the fixture needs a 60V constant current driver. The -40°C to +85°C operating temperature range supports broad ambient conditions.

Can I use this driver for 60V LED signage lighting?

Yes, if the signage lighting assembly is designed for constant current operation between 36V and 60V and does not exceed 156W or 2.6A. Its rating makes it more suitable for larger sign lighting systems than for small low-load applications.

What is the maximum 60V LED strip load for the HBG-160-60A?

The driver is rated for 156W maximum output, so strip length can be estimated with 156W / strip watts per meter. That gives the maximum meters based on your strip's rated power. Check your strip rated power per meter and confirm it is compatible with a 60V constant current driver.

Can the HBG-160-60A be used in rainy or washdown areas?

This model is IP65 water-resistant, so it is appropriate for dust protection and water spray exposure. If the environment needs a fully waterproof rating, the IP67 versions in the same family are the better match.

How does the HBG-160-60A compare with the other HBG-160 voltage versions?

The HBG-160 family steps through 24V at 156W and 6.5A, 36V at 158.4W and 4.4A, 48V at 158.4W and 3.3A, and 60V at 156W and 2.6A, with each version having its own CC voltage range. The HBG-160-60A is the adjustable 60V model with a 36-60V CC range.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well HBG-160-60B Power Supply 160W 60V - Dimmable 2.6A	156W	60V	2.6A	IP67	$62.31	View
Mean Well HBG-160-48B Power Supply 160W 48V - Dimmable 3.3A	158.4W	48V	3.3A	IP67	$64.21	View
Mean Well HBG-160-36A Power Supply 160W 36V - Adjustable 4.4A	158.4W	36V	4.4A	IP65	$60.58	View
Mean Well HBG-160-60DA Power Supply 160W 60V - DALI 2.6A	156W	60V	2.6A	IP67	$67.19	View
Mean Well HBG-160-60AB Power Supply 160W 60V - Adjustable and Dimmable 2.6A	156W	60V	2.6A	IP65	$63.25	View
Mean Well HBG-160-60 Power Supply 160W 60V 2.6A	156W	60V	2.6A	IP67	$52.25	View
Mean Well HBG-160-48DA Power Supply 160W 48V - DALI 3.3A	158.4W	48V	3.3A	IP67	$67.19	View
Mean Well HBG-160-48AB Power Supply 160W 48V - Adjustable and Dimmable 3.3A	158.4W	48V	3.3A	IP65	$63.25	View
Mean Well HBG-160-48A Power Supply 160W 48V - Adjustable 3.3A	158.4W	48V	3.3A	IP65	$62.42	View
Mean Well HBG-160-48 Power Supply 160W 48V 3.3A	158.4W	48V	3.3A	IP67	$52.25	View
