Mean Well SCWN03E-03 DC-DC Converter - 3W 4.5~9V DC in 3.3V out
Description
Description
The SCWN03E is a 3W Mean Well power converter (input range: 4.5~9Vdc).
Key Features
- ✓ Input voltage range: 4.5~9Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating3 Watt
-
Output Voltage3.3 Volt
-
Rated Current0.6 Ampere
-
Input Voltage4.5V~9V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.4 in
-
Weight0.03 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SCWN03E-03 to power a 3.3V embedded controller in industrial equipment?
Yes, this model is designed for constant-voltage 3.3V output and is rated for 3W total. Its 0.6A output current makes it suitable for low-power 3.3V embedded control boards that stay within that power budget.
Is this converter a fit for 3.3V industrial sensor or monitoring electronics?
It can be a fit for low-power 3.3V sensor and monitoring circuits where the load does not exceed 3W or 0.6A. The unit provides constant-voltage output and accepts a 4-9VAC input range.
Can the SCWN03E-03 be used in compact automation or embedded assemblies?
Yes, its small 31.8 × 20.3 × 10.2 mm package supports compact embedded and automation designs. It is intended for low-power 3.3V electronics rather than higher-current loads.
What is the difference between the SCWN03E-03 and the other SCWN03E models?
All SCWN03E versions in this group are 3W converters with the same 31.8 × 20.3 × 10.2 mm size. The SCWN03E-03 outputs 3.3V at 0.6A, the SCWN03E-05 outputs 5V at 0.6A, the SCWN03E-12 outputs 12V at 0.25A, and the SCWN03E-15 outputs 15V at 0.2A.
Is the SCWN03E-03 suitable for outdoor or harsh-temperature use?
The published specs show an operating temperature range of -40°C to +90°C, which supports wide-temperature operation. No IP rating is listed, so the specs do not identify it as an outdoor or weather-exposed converter.
