Description
Description
Features
2: 1 wide input range |
4: 1 wide input range (option) |
1500VDC I / O isolation |
3000VDC I / O isolation (option) |
Built-in EMI filter |
Protection: Short circuit / Overload |
Cooling by free air convection |
Six-sided shield metal case |
100% full load burn-in test |
Low cost, high reliability |
Approvals: FCC / EAC / CE / UKCA |
2 years warranty |
General Specification
Voltage set point accuracy | ±2.0% (max.) |
Line regulation | ±0.3% (max.) |
Load regulation | ±0.5% (max.) @ 10 ~ 100% load |
Overload protection | 160% to 250%, auto-recovery |
Efficiency | 85% (typical) |
Short circuit protection | Continuous, auto-recovery |
I / O isolation voltage | 1000VDC (min.) |
I / O isolation resistance | 100MQ(min.)@500VDC |
Working temperature | -25 ~ + 71°C (refer to output derating curve) |
Storage temperature | -25°C to + 105°C |
EMC | Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8, FCC part15 class B |
Temp. Coefficient | ± 0.03% / ° C (max.) |
Dimension (LxWxH) (mm) | 50.8 x 25.4 x 11.2mm or 2" x 1" x 0.44" inch |
Case material | Six-sided shield metal case |
Specifications
Specifications
-
BrandMean Well
-
SeriesSKE Series
-
Power Rating10 Watt
-
Output Voltage12 Volt
-
Rated Current0.84 Ampere
-
Input Voltage9V~18V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~71°C
-
Warranty2 Year
-
Length2 in
-
Width1 in
-
Height0.44 in
-
Weight0.07 lb
