Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well SPRN01L-05 DC-DC Converter - 1W - 4.75~5.5V in 5V out
Description
Description
Features
| SIP6 package with industry-standard pinout |
| Wide operating temperature range -40~+90°C |
| Comply to BS EN/EN55032 radiated Class B without additional components |
| Low cost |
| Protection: Short circuit |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±3% |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max. |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.05% / ℃ (0 ~ 71℃) |
| Dimension (LxWxH) (mm) | 19.6*7.1*10.14mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage4.75V~5.5V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01L-05 in a 5V industrial control board that only has a 4.75~5.5V source available?
Yes, this converter is designed for a 4.75~5.5V input and provides a regulated 5V constant-voltage output. With 1W total power, it fits low-power control, monitoring, and embedded electronics that stay within that output limit.
Is the SPRN01L-05 suitable for low-power embedded 5V logic or sensor circuits?
It can be used for low-power 5V embedded electronics because it delivers a 5V constant-voltage output from a 4.75~5.5V input range. The unit is rated at 1W, so it is intended for small loads rather than higher-power 5V devices.
Can I use this DC-DC converter for compact automation electronics where board space is limited?
Yes, its 19.6 × 10.14 × 7.1 mm size and 0.0025 kg weight make it suitable for compact industrial and embedded assemblies. It is a practical fit where a small 5V constant-voltage converter is needed within a 1W power budget.
Would the SPRN01L-05 work in equipment exposed to wide temperature swings?
It is rated for operation from -40°C to +90°C, which supports demanding temperature conditions inside industrial or embedded equipment. No IP rating is listed in the provided specs, so it is better suited to protected indoor enclosures than exposed outdoor locations.
How does the SPRN01L-05 compare with the other SPRN01L models?
The SPRN01L-05, SPRN01L-12, and SPRN01L-15 are all 1W converters with the same 19.6 × 10.14 × 7.1 mm dimensions, 0.0025 kg weight, and -40°C to +90°C operating range. The difference is output: the SPRN01L-05 is 5V, the SPRN01L-12 is 12V at 0.08A, and the SPRN01L-15 is 15V at 0.07A.
