Mean Well SPRN01M-05 DC-DC Converter - 1W - 11.4~13.2V in 5V out
Description
Description
Features
| SIP6 package with industry-standard pinout |
| Wide operating temperature range -40~+90°C |
| Comply to BS EN/EN55032 radiated Class B without additional components |
| Low cost |
| Protection: Short circuit |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±3% |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max. |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.05% / ℃ (0 ~ 71℃) |
| Dimension (LxWxH) (mm) | 19.6*7.1*10.14mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage11.4V~13.2V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01M-05 in a 12V-class industrial system to power low-power 5V electronics?
Yes, this model accepts an 11.4~13.2V input and provides a 5V constant-voltage output. Its 1W rating makes it suitable for low-power embedded, monitoring, and control electronics in 12V-class equipment.
Is the SPRN01M-05 appropriate for a compact embedded controller powered from an 11.4~13.2V source?
It is designed for exactly that input range and converts it to a regulated 5V output. The 19.6 × 10.14 × 7.1 mm body and 0.0025 kg weight also suit compact board-level designs.
Can this converter be used for low-power 5V logic in automation panels?
Yes, it provides a constant 5V output and is intended for 1W applications, which fits light-duty logic and auxiliary circuitry. It is a better match for small control electronics than for higher-power 5V loads.
Is the SPRN01M-05 suitable for outdoor equipment cabinets?
The operating temperature range is -40°C to +90°C, so it can tolerate broad thermal conditions inside equipment. No IP rating is listed in the provided specifications, so it is better used in protected indoor or enclosed installations rather than exposed outdoor locations.
How does the SPRN01M-05 compare with the other SPRN01M models?
The SPRN01M-05, SPRN01M-12, and SPRN01M-15 all share a 1W rating, 19.6 × 10.14 × 7.1 mm dimensions, 0.0025 kg weight, and -40°C to +90°C operating range. The output differs: the SPRN01M-05 is 5V, the SPRN01M-12 is 12V at 0.08A, and the SPRN01M-15 is 15V at 0.07A.
