Mean Well SPRN01O-05 DC-DC Converter - 1W - 45.6~52.8V in 5V out
Description
Description
Features
| SIP6 package with industry-standard pinout |
| Wide operating temperature range -40~+90°C |
| Comply to BS EN/EN55032 radiated Class B without additional components |
| Low cost |
| Protection: Short circuit |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±3% |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max. |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.05% / ℃ (0 ~ 71℃) |
| Dimension (LxWxH) (mm) | 19.6*7.1*10.14mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage45.6V~52.8V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01O-05 to derive 5V from a 45-52VAC source for embedded electronics?
Yes, it is designed for a constant 5V output when the input is within the listed 45-52VAC range. With a 1W power rating, it is intended for low-power embedded electronics and small logic loads rather than larger 5V equipment.
Is the SPRN01O-05 a good choice for low-power industrial monitoring or communication boards?
It can fit compact industrial monitoring or communication circuits that need 5V and are fed from a 45-52VAC source. The 1W output rating makes it appropriate for light auxiliary board-level power, not higher-demand 5V subsystems.
Could this converter be used in automation systems for isolated 5V support power?
For automation designs that need a small constant 5V rail from a 45-52VAC source, this model can be suitable. Its use case is limited by the 1W rating, so it is better for support electronics, control logic, or signal interfaces than for larger 5V loads.
Is the SPRN01O-05 suitable for outdoor or high-temperature equipment?
The operating temperature range is listed as -40°C to +90°C, so the temperature capability is broad. Because no IP rating is provided in the specs, it should generally be treated as a protected internal component unless the final enclosure provides the necessary environmental sealing.
How does the SPRN01O-05 compare with other SPRN01O output versions?
The listed SPRN01O siblings are all 1W models in the same series. The SPRN01O-05 is 5V at 200A, the SPRN01O-12 is 12V at 0.08A, and the SPRN01O-15 is 15V at 0.07A.
