Mean Well SPRN01N-15 DC-DC Converter - 1W - 22.8~26.4V in 15V out
Description
Description
The SPRN01N is a 1W Mean Well power converter (input range: 4.75~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.75~5.5Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage22.8V~26.4V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01N-15 to provide 15V for a compact automation interface board?
It can be used for low-power automation or interface electronics that need a constant 15V rail, as long as the source is within 22-26VAC. The output is limited to 1W and 0.07A, so it is intended for light auxiliary circuitry rather than larger 15V devices.
Is this 15V converter suitable for industrial measurement or signal-conditioning modules?
For small measurement or signal-conditioning functions that require 15V, this model can fit if the input supply falls in the 22-26VAC range. Its 1W maximum output and 0.07A current rating make it a low-power option.
Could the SPRN01N-15 be used in embedded equipment that needs a dedicated 15V auxiliary rail?
Yes, for embedded equipment with a modest 15V requirement, this converter can provide constant voltage output from a 22-26VAC source. The 1W limit means it is best for small support rails, bias circuits, or other low-demand embedded functions.
Does the SPRN01N-15 handle demanding temperature conditions?
The specified operating range is -40°C to +90°C, which supports use across a wide industrial temperature span. No IP rating is shown in the provided specs, so environmental sealing for outdoor or washdown exposure would need to come from the host enclosure.
What are the differences between SPRN01N-05, SPRN01N-12, and SPRN01N-15?
All listed SPRN01N versions are rated at 1W. The SPRN01N-05 outputs 5V at 200A, the SPRN01N-12 outputs 12V at 0.08A, and the SPRN01N-15 outputs 15V at 0.07A.
