Mean Well SPRN01M-15 DC-DC Converter - 1W - 11.4~13.2V in 15V out
Description
Description
Features
| SIP6 package with industry-standard pinout |
| Wide operating temperature range -40~+90°C |
| Comply to BS EN/EN55032 radiated Class B without additional components |
| Low cost |
| Protection: Short circuit |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±3% |
| Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes |
| Cooling | Free-air convection |
| Short circuit protection | SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max. |
| Working temperature | -40°C to +90°C |
| EMC | Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.05% / ℃ (0 ~ 71℃) |
| Dimension (LxWxH) (mm) | 19.6*7.1*10.14mm |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSPRN Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage11.4V~13.2V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SPRN01M-15 to derive 15V for a small industrial sensor or transducer?
It can fit low-power industrial or embedded loads that need a constant 15V output, as long as the source is within the listed 11-13VAC input range. The output is limited to 1W and 0.07A, so it is suited to light auxiliary sensor or signal-conditioning duty rather than larger 15V loads.
Is this 15V converter suitable for embedded control boards that need an isolated low-power rail?
For compact embedded electronics that only need a small constant 15V rail, this model can be an option if the available input falls within 11-13VAC. Its 1W rating and 0.07A output make it appropriate for low-demand support circuitry, not higher-draw control hardware.
Can the SPRN01M-15 be used in automation equipment for analog interface or measurement circuits?
It can work for low-power automation subcircuits that require a steady 15V output and stay within 0.07A. The key checks are the 11-13VAC input window and the 1W output limit, which keep it in the range of light analog or measurement support tasks.
Is the SPRN01M-15 appropriate for harsh temperature environments?
The specified operating temperature range is -40°C to +90°C, which supports use across a wide span of industrial temperature conditions. No IP rating is listed in the provided specs, so indoor or enclosed use is the safer assumption unless the finished system provides the required environmental protection.
How does the SPRN01M-15 compare with the other SPRN01M versions?
Within the SPRN01M series, all listed models are 1W converters. The SPRN01M-05 is 5V with 200A, the SPRN01M-12 is 12V with 0.08A, and the SPRN01M-15 is 15V with 0.07A.
