Mean Well SPRN01O-15 DC-DC Converter - 1W - 45.6~52.8V in 15V out

SKU:
SPRN01O-15

$5.35 USD
Shipping calculated at checkout.
|

Your order will be processed within 24 hours

Description

Features

SIP6 package with industry-standard pinout
Wide operating temperature range -40~+90°C
Comply to BS EN/EN55032 radiated Class B without additional components
Low cost
Protection: Short circuit
1.5KVDC I/O isolation
3 years warranty

General Specification

Voltage accuracy ±3%
Vibration 10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes
Cooling Free-air convection
Short circuit protection SPRN01: Current limit protection 60 sec. max., DPRN01: 1 sec. max.
Working temperature -40°C to +90°C
EMC Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8
Temp. Coefficient 0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm) 19.6*7.1*10.14mm
Potting material UL 94V-0 rated

Specifications

  • Brand
    Mean Well
  • Series
    SPRN Series
  • Power Rating
    1 Watt
  • Output Voltage
    15 Volt
  • Rated Current
    0.06 Ampere
  • Input Voltage
    45.6V~52.8V
  • No of Output
    1
  • Dimming Control
    None
  • Standards Met
    CE,EMC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~90°C
  • Warranty
    3 Year
  • Length
    0.77 in
  • Width
    0.4 in
  • Height
    0.28 in
  • Weight
    0.01 lb

File Downloads

::specification::
