Mean Well PWM-60-48 Power Supply 60W 48V - Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PWM-60-48 Power Supply 60W 48V - Dimmable
The PWM-60 is a 60W Mean Well DIN rail power converter with a 150mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 150mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.5 UL8750( type ”HL” )( except for DA-Type), UL879( for 12V,24V Blank Type only), CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13 independent,EN62384, IP67,BIS IS15885(for 12,24,48 Blank Type only), EAC TP TC 004, GB19510.1, GB19510.14
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPWM Series
-
Power Rating60 Watt
-
Output Voltage48 Volt
-
Rated Current1.25 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.91 in
-
Width2.09 in
-
Height1.38 in
-
Weight1.08 lb
::specification::
Frequently Asked Questions
What types of LED lighting applications use a 48V dimmable driver like the PWM-60-48?
48V LED strips and luminaires are increasingly used in longer runs and in Power over Ethernet (PoE) compatible systems where lower current reduces resistive losses. The PWM-60-48 is suited to 48V architectural strip systems, long-run cove lighting, and specialty 48V luminaires that benefit from reduced voltage drop over distance.
Can the PWM-60-48 be installed in a damp or outdoor location?
Yes. The IP67 rating certifies protection against dust and temporary water immersion, so the driver can be placed in outdoor enclosures, wet-area sign boxes, or exposed architectural installations. Its operating temperature spans -40°C to +85°C, covering a wide range of outdoor climates.
How long a 48V LED strip can the PWM-60-48 power?
The PWM-60-48 provides a maximum of 60W at 48V and 1.25A. For a 10 W/m strip, the theoretical maximum is 6 meters; at 20 W/m it is 3 meters. Always check your strip's specific power rating per meter, and derate to 80% load (48W) for continuous operation to protect driver longevity.
Is the PWM-60-48 compatible with a PWM dimming signal from a building automation controller?
Yes. The built-in 3-in-1 dimming accepts 0–10V, PWM signal, and resistance inputs. A standard PWM dimming output from a building controller or smart relay will control the LED output smoothly without additional hardware.
Can I use the PWM-60-48 for dimmable 48V retail display lighting?
Yes. The combination of 60W output, IP67 enclosure, and 3-in-1 dimming makes the PWM-60-48 suitable for commercial retail display applications using 48V LED strips. The Class II design without FG simplifies mounting in plastic display cabinetry.
How does the PWM-60-48 compare to the other 60W PWM series voltage options?
The 60W PWM family in this voltage tier includes the PWM-60-24 (24V, 2.5A), PWM-60-36 (36V, 1.67A), and PWM-60-48 (48V, 1.25A), all sharing the same 150 × 53 × 35 mm housing and IP67 rating. Higher voltage means lower current for the same wattage, which can reduce resistive losses over longer cable runs.
