Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well EPS-65-3.3-C Power Supply 36W 3.3V
The EPS-65-3.3 is a 65W Mean Well power converter (input range: 90~264VAC, operating temperature: -30~+70°C).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -30~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesEPS Series
-
Power Rating36.3 Watt
-
Output Voltage3.3 Volt
-
Rated Current11 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length4.07 in
-
Width2.44 in
-
Height1.46 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the EPS-65-3.3-C for a 3.3V OEM control assembly with higher current demand?
Yes, if the assembly needs a constant 3.3V output and the load stays within 11A and 36.3W. That makes it suitable for 3.3V control electronics, processor boards, and embedded assemblies with heavier low-voltage current draw.
Is the EPS-65-3.3-C a fit for industrial computing or logic-level electronics that run on 3.3V?
It can be used where the end device is designed for a fixed 3.3V input and requires up to 11A. Compared with lower-current 3.3V models in the same series, this version supports larger 3.3V loads up to 36.3W.
Can this model power 3.3V monitoring, sensing, or automation boards inside machinery?
Yes, for 3.3V constant-voltage boards and electronics whose combined demand is no more than 11A. Its 90-264VAC input also suits equipment that may be deployed across different AC mains ranges.
Is the EPS-65-3.3-C suitable for outdoor use?
The listed operating range is -30°C to +70°C, but no IP rating is provided in the specs. That points to use in protected indoor equipment or enclosures rather than direct outdoor exposure.
What is the difference between EPS-65-3.3-C and the other 3.3V EPS power supplies?
The listed 3.3V siblings are EPS-15-3.3 at 9.9W and 3A, EPS-25-3.3 at 16.5W and 5A, EPS-35-3.3 at 19.8W and 6A, EPS-45-3.3 and EPS-45-3.3-C at 26.4W and 8A, EPS-45S-3.3 at 26.4W and 8A, EPS-65S-3.3 at 33W and 10A, and EPS-65-3.3 / EPS-65-3.3-C at 36.3W and 11A. For physical size, EPS-65-3.3-C is listed at 103.4 × 62.0 × 37.0 mm and 0.3 kg, while EPS-65-3.3 is 101.6 × 50.8 × 29.0 mm and 0.15 kg.
