Mean Well EPS-65-7.5-C Power Supply 60W 7.5V
The EPS-65-7.5 is a 65W Mean Well power converter (input range: 90~264VAC, operating temperature: -30~+70°C).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -30~+70°C
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368- TUV EN62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesEPS Series
-
Power Rating60 Watt
-
Output Voltage7.5 Volt
-
Rated Current8 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length4.07 in
-
Width2.44 in
-
Height1.46 in
-
Weight0.66 lb
::specification::
Frequently Asked Questions
Can I use the EPS-65-7.5-C for a 7.5V industrial controller or embedded subsystem?
Yes, if the subsystem requires a constant-voltage 7.5V DC source and draws no more than 8A or 60W. That output level fits higher-demand 7.5V embedded and industrial electronics better than lower-power 7.5V models.
Is the EPS-65-7.5-C a good fit for OEM equipment that uses a fixed 7.5V rail?
It can be a fit for OEM designs that need regulated 7.5V DC up to 8A and 60W from a 90-264VAC input. Its compact 103.4 × 62.0 × 37.0 mm form factor supports internal mounting in equipment where space matters.
Can the EPS-65-7.5-C support several 7.5V electronics loads in one enclosure?
Yes, as long as the total current stays within 8A and the combined power stays within 60W. It is intended for constant-voltage 7.5V applications rather than loads that need another nominal DC voltage.
Would the EPS-65-7.5-C work for 7.5V instrumentation or specialty control electronics?
It can, if the equipment is specified for a 7.5V constant-voltage supply and requires no more than 8A. The 0.3 kg weight and 103.4 × 62.0 × 37.0 mm size are useful where the power supply has to fit inside compact equipment.
Can the EPS-65-7.5-C operate in colder or hotter environments?
The listed operating temperature range is -30°C to +70°C, so it is designed for a wide thermal window. Since no IP rating is provided in the specs, environmental exposure protection has to be handled by the end enclosure if needed.
How does the EPS-65-7.5-C compare with the other 7.5V EPS models?
The listed 7.5V siblings are EPS-15-7.5 at 15W and 2A, EPS-25-7.5 at 25.5W and 3.4A, EPS-35-7.5 at 35.25W and 4.7A, EPS-45-7.5 and EPS-45-7.5-C at 40.5W and 5.4A, EPS-45S-7.5 at 40.5W and 5.4A, EPS-65-7.5 at 60W and 8A, and EPS-65S-7.5 at 60W and 8A. EPS-65-7.5-C sits at the top of the listed 7.5V range with 60W and 8A.
