Mean Well

Mean Well LDD-300H DC/DC LED Driver CC 300mA - Step-down

Name: Mean Well LDD-300H DC/DC LED Driver CC 300mA - Step-down
Brand: Mean Well
SKU: LDD-300H
Price: 9.21 USD
Availability: InStock

Mean Well LDD-300H DC/DC LED Driver CC 300mA - Step-down

20 units in stock

$9.21 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

View full details

Current accuracy	±3% at 24VDC input ; ±4% at 48VDC input for LDD-H/HW ; ±5% for LDD-HS
Over temperature protection	Protection type : Shut down, recovers automatically after temperature goes down
Efficiency	97% at full load and 36VDC/48VDC input for LDD-H/HW ; 96% at full load and 36VDC/48VDC input for LDD-HS(typical)
Short circuit protection	Regulated at rated output current
Working temperature	-40°C to +85°C
EMC	Compliance to EN55015 class B, EN61000-4-2,3,4,6,8, EAC TP TC 020
Temp. Coefficient	±0.03% / °C
Dimension (LxWxH) (mm)	31.820.312.2mm or 1.25"0.8"0.48" inch for LDD-H/HW ; 31.820.311.4mm or 1.25"0.8"0.45" inch for LDD-HS
Potting material	Expoxy(UL94-V0) for LDD-H/HW ; without potted for LDD-HS
